DC3332210 SAB Tray Cables
Part#:DC3332210
Manufacturer:SAB
Product Lifecycle:Active
Get a quick Quote!
DC 105 - 22 AWG/10c, flexible oil resistant data cable, UL, CSA, CE, RoHS
About the manufacturer: SAB is one of the manufacturers that offers Tray Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.
Check out the DC3332210 SAB price in the box on the right side or send a quick quote.
Product Details
- Color Grayish Tan
- Weight 27.22 g
- Chemical Resistant NO
- Oil Resistant No
- UV Resistant NO
- Halogen Free NO
- Submersible NO
- Direct Burial NO
- Movement Type Stationary/Flexible
- Application Data
- Gauge 22 AWG
- Number of conductors 10
- Cable configuration 22 AWG (≈ 7/30)/10c
- Stranding type tinned copper fine strands
- Insulation type Semi-rigid PVC
- Shielded No
- Voltage 300
- Approvals UL PLTC/ITC, UL CMG, CSA AWM, CSA CMG, CE, RoHS
- RoHS YES
- Temperature range -25°C to +105°C
- Outside diameter (OD) 0.289 in
- UOM ft
- CSA Certification YES
- UL Certification YES
- CE Certification YES
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
DC3332210 Description
SAB DC3332210 Tray Cable is part of DC 105 product family, and is designed for Data applications. This cable is 22 AWG with 10 conductors, and 22 AWG (≈ 7/30)/10c cable configuration. Featuring Grayish Tan color jacket, Semi-rigid PVC insulation, and tinned copper fine strands stranding. It has 0.289 in OD, constructed to support Stationary/Flexible movement type, and rated for 300 volts. This Data cable can operate in -25°C to +105°C temperature range, it is and has following approvals: UL PLTC/ITC, UL CMG, CSA AWM, CSA CMG, CE, RoHS. This cable is an excellent choice for Data applications.
