7971403 SAB Torsional Cables

SAB 7971403 RT 113 - 14 AWG/3c, Torsional PVC cable for moderate stress, �270� torsion
SAB

Part#:7971403

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

RT 113 - 14 AWG/3c, Torsional PVC cable for moderate stress, �270� torsion

About the manufacturer: SAB is one of the manufacturers that offers Torsional Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 7971403 SAB price in the box on the right side or send a quick quote.

Product Details

  • Voltage
    600
  • UOM
    ft
  • Oil Resistant
    Yes
  • Movement Type
    Torsional
  • Stranding type
    bare copper strands, class 6
  • UV Resistant
    YES
  • Direct Burial
    NO
  • Cable configuration
    14 AWG (≈ 140/34)/3c
  • Approvals
    UR AWM, CSA AWM, CE, EAC, RoHS
  • UL Certification
    YES
  • Temperature range
    -40°C to +90°C
  • Insulation type
    PVC
  • CE Certification
    YES
  • Halogen Free
    NO
  • Application
    Control, Data
  • Shielded
    No
  • Weight
    44.45 g
  • Submersible
    NO
  • Number of conductors
    3
  • RoHS
    YES
  • CSA Certification
    YES
  • Color
    Black
  • Outside diameter (OD)
    0.386 in
  • Chemical Resistant
    NO
  • Gauge
    14 AWG

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


7971403 Description

SAB 7971403 Torsional Cable is part of RT 113 product family, and is designed for Control, Data applications. This cable is 14 AWG with 3 conductors, and 14 AWG (≈ 140/34)/3c cable configuration. Featuring Black color jacket, PVC insulation, and bare copper strands, class 6 stranding. It has 0.386 in OD, constructed to support Torsional movement type, and rated for 600 volts. This Control, Data cable can operate in -40°C to +90°C temperature range, it is oil resistant, UV resistand, and has following approvals: UR AWM, CSA AWM, CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.
