7740503 SAB Multiconductor Cables

Name: 7740503
Brand: SAB

SAB 7740503 SD 200 - 22 AWG/5c, halogen free continuous flex oil resistant data & control cable, CE, RoHS

Part#:7740503

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SD 200 - 22 AWG/5c, halogen free continuous flex oil resistant data & control cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Multiconductor Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 7740503 SAB price in the box on the right side or send a quick quote.

Product Details

Weight
9.14 g
Movement Type
Continuous Flex
Color
Grayish Tan
UOM
ft
Temperature range
-50°C to +90°C
CE Certification
YES
UV Resistant
NO
Shielded
No
Chemical Resistant
YES
Direct Burial
NO
Stranding type
bare copper, extra fine strands
CSA Certification
NO
Insulation type
TPE
Voltage
300
Gauge
22 AWG
RoHS
YES
UL Certification
NO
Oil Resistant
Yes
Application
Control, Data
Number of conductors
5

Submersible

Cable configuration

22 AWG (≈ 42/38)/5c

Outside diameter (OD)

0.169 in

Halogen Free

YES

Approvals

CE, EAC, RoHS

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

7740503 Description

SAB 7740503 Continuous Flex Cable is part of SD 200 product family, and is designed for Control, Data applications. This cable is 22 AWG with 5 conductors, and 22 AWG (≈ 42/38)/5c cable configuration. Featuring Grayish Tan color jacket, TPE insulation, and bare copper, extra fine strands stranding. It has 0.169 in OD, constructed to support Continuous Flex movement type, and rated for 300 volts. This Control, Data cable can operate in -50°C to +90°C temperature range, it is chemical resistant, oil resistant, Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.
