64461225 SAB Halogen Free Cables

Name: 64461225
Brand: SAB

SAB 64461225 SABIX BL 446 C FRNC TP - 24 AWG/12pr, shielded halogen-free flame retardant paired flexible data cable for shipboard, DNV-GL, CE, RoHS

Part#:64461225

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX BL 446 C FRNC TP - 24 AWG/12pr, shielded halogen-free flame retardant paired flexible data cable for shipboard, DNV-GL, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 64461225 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Pigeon Blue
Weight
72.12 g
Chemical Resistant
NO
Oil Resistant
No
UV Resistant
NO
Halogen Free
YES
Submersible
NO
Direct Burial
NO
Movement Type
Stationary/Flexible
Application
Control, Data
Gauge
24 AWG
Pair count
12
Number of conductors
24
Cable configuration
24 AWG (≈ 14/34)/12pr
Stranding type
tinned copper strands, class 5
Insulation type
SABIX
Shielded
Yes
Voltage
300
Approvals
DNV, CE, EAC, RoHS
RoHS
YES

Temperature range

-40°C to +90°C

Outside diameter (OD)

0.500 in

UOM

CSA Certification

UL Certification

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

64461225 Description

SAB 64461225 Halogen Free Cable is part of SABIX® BL 446 C FRNC TP product family, and is designed for Control, Data applications. This cable is 24 AWG with 24 conductors, and shielded 24 AWG (≈ 14/34)/12pr cable configuration. Featuring Pigeon Blue color jacket, SABIX insulation, and tinned copper strands, class 5 stranding. It has 0.5 in OD, constructed to support Stationary/Flexible movement type, and rated for 300 volts. This Control, Data cable can operate in -40°C to +90°C temperature range, it is Halogen free, and has following approvals: DNV, CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.
