64430734 SAB Halogen Free Cables

Name: 64430734
Brand: SAB

SAB 64430734 SABIX BL 443 C FRNC TT - 22 AWG/7tr, shielded halogen-free flame retardant flexible data cable for shipboard, DNV-GL, CE, RoHS

Part#:64430734

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX BL 443 C FRNC TT - 22 AWG/7tr, shielded halogen-free flame retardant flexible data cable for shipboard, DNV-GL, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 64430734 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Pigeon Blue
Weight
61.69 g
Chemical Resistant
NO
Oil Resistant
No
UV Resistant
NO
Halogen Free
YES
Submersible
NO
Direct Burial
NO
Movement Type
Stationary/Flexible
Application
Control, Data
Gauge
22 AWG
Number of conductors
7tr
Cable configuration
22 AWG (≈ 7/30)/7tr
Stranding type
tinned copper strands, class 5
Insulation type
SABIX
Shielded
Yes
Voltage
300
Approvals
DNV, CE, EAC, RoHS
RoHS
YES
Temperature range
-40°C to +90°C

Outside diameter (OD)

0.469 in

UOM

CSA Certification

UL Certification

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

64430734 Description

SAB 64430734 Halogen Free Cable is part of SABIX® BL 443 C FRNC TT product family, and is designed for Control, Data applications. This cable is 22 AWG with 7tr conductors, and shielded 22 AWG (≈ 7/30)/7tr cable configuration. Featuring Pigeon Blue color jacket, SABIX insulation, and tinned copper strands, class 5 stranding. It has 0.469 in OD, constructed to support Stationary/Flexible movement type, and rated for 300 volts. This Control, Data cable can operate in -40°C to +90°C temperature range, it is Halogen free, and has following approvals: DNV, CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.
