63451650 SAB Halogen Free Cables

Name: 63451650
Brand: SAB

SAB 63451650 SABIX D 345 FRNC TP - 20 AWG/16pr, halogen-free flame retardant paired data cable, CE, RoHS

Part#:63451650

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX D 345 FRNC TP - 20 AWG/16pr, halogen-free flame retardant paired data cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 63451650 SAB price in the box on the right side or send a quick quote.

Product Details

UV Resistant
NO
CE Certification
YES
Outside diameter (OD)
0.642 in
UL Certification
NO
Temperature range
-40°C to +85°C
CSA Certification
NO
Weight
110.63 g
Chemical Resistant
NO
Submersible
NO
Number of conductors
32
Color
Grayish Tan
Gauge
20 AWG
Insulation type
SABIX
Direct Burial
NO
Pair count
16
Shielded
Yes
RoHS
YES
Movement Type
Stationary/Flexible
Cable configuration
20 AWG (≈ 16/32)/16pr
Voltage
500

Approvals

CE, EAC, RoHS

Application

Data

Stranding type

bare copper, fine strands

Oil Resistant

Halogen Free

YES

UOM

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

63451650 Description

SAB 63451650 Halogen Free Cable is part of SABIX® D 345 FRNC TP product family, and is designed for Data applications. This cable is 20 AWG with 32 conductors, and shielded 20 AWG (≈ 16/32)/16pr cable configuration. Featuring Grayish Tan color jacket, SABIX insulation, and bare copper, fine strands stranding. It has 0.642 in OD, constructed to support Stationary/Flexible movement type, and rated for 500 volts. This Data cable can operate in -40°C to +85°C temperature range, it is Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Data applications.
