62850305 SAB Halogen Free Cables

Name: 62850305
Brand: SAB

Part#:62850305

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX A 285 FRNC X - 20 AWG/3c, shielded halogen-free flame retardant control cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 62850305 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Black
Weight
13.61 g
Chemical Resistant
YES
Oil Resistant
Yes
UV Resistant
YES
Halogen Free
YES
Submersible
NO
Direct Burial
NO
Movement Type
Stationary/Flexible
Application
Control, Power
Gauge
20 AWG
Number of conductors
3
Cable configuration
20 AWG (≈ 16/32)/3c
Stranding type
tinned copper strands, class 5
Insulation type
SABIX
Shielded
Yes
Voltage
500
Approvals
CE, EAC, RoHS
RoHS
YES
Temperature range
-50°C to +125°C

Outside diameter (OD)

0.205 in

UOM

CSA Certification

UL Certification

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

62850305 Description

SAB 62850305 Halogen Free Cable is part of SABIX® A 285 FRNC X product family, and is designed for Control, Power applications. This cable is 20 AWG with 3 conductors, and shielded 20 AWG (≈ 16/32)/3c cable configuration. Featuring Black color jacket, SABIX insulation, and tinned copper strands, class 5 stranding. It has 0.205 in OD, constructed to support Stationary/Flexible movement type, and rated for 500 volts. This Control, Power cable can operate in -50°C to +125°C temperature range, it is chemical resistant, oil resistant, UV resistand, Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.
