61572786 SAB Halogen Free Cables

SAB 61572786 SABIX A 157 FRNC - 12 AWG/1c, flame retardant halogen-free 1000V green/yellow hook-up wire, UL, CE, RoHS
SAB

Part#:61572786

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX A 157 FRNC - 12 AWG/1c, flame retardant halogen-free 1000V green/yellow hook-up wire, UL, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 61572786 SAB price in the box on the right side or send a quick quote.

Product Details

  • Voltage
    1000
  • UL Certification
    YES
  • Oil Resistant
    No
  • Direct Burial
    NO
  • Cable configuration
    12 AWG/1c
  • Outside diameter (OD)
    0.169 in
  • Chemical Resistant
    NO
  • Submersible
    NO
  • Number of conductors
    1
  • UV Resistant
    YES
  • Application
    Control, Power
  • Shielded
    No
  • RoHS
    YES
  • CSA Certification
    NO
  • Weight
    14.06 g
  • Movement Type
    Stationary/Flexible
  • Stranding type
    bare copper strands, class 5
  • Approvals
    UR AWM, CE, EAC, RoHS
  • UOM
    ft
  • Halogen Free
    YES
  • Gauge
    12 AWG
  • Color
    Green/Yellow
  • Temperature range
    -40°C to +90°C
  • CE Certification
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

61572786 Description

SAB 61572786 Halogen Free Cable is part of SABIX® A 157 FRNC product family, and is designed for Control, Power applications. This cable is 12 AWG with 1 conductors, and 12 AWG/1c cable configuration. Featuring Green/Yellow color jacket, and bare copper strands, class 5 stranding. It has 0.169 in OD, constructed to support Stationary/Flexible movement type, and rated for 1000 volts. This Control, Power cable can operate in -40°C to +90°C temperature range, it is UV resistand, Halogen free, and has following approvals: UR AWM, CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.

Related documents 61572786 Specs

61572786 SABIX_A_147_FRNC-SABIX_A_157_FRNC.pdf
