61470950 SAB Halogen Free Cables

Name: 61470950
Brand: SAB

SAB 61470950 SABIX A 147 FRNC - 20 AWG/1c, flame retardant halogen-free 600V orange hook-up wire, UL, CE, RoHS

Part#:61470950

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX A 147 FRNC - 20 AWG/1c, flame retardant halogen-free 600V orange hook-up wire, UL, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 61470950 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Orange
Weight
3.63 g
Chemical Resistant
NO
Oil Resistant
No
UV Resistant
YES
Halogen Free
YES
Submersible
NO
Direct Burial
NO
Movement Type
Stationary/Flexible
Application
Control, Power
Gauge
20 AWG
Number of conductors
1
Cable configuration
20 AWG/1c
Stranding type
bare copper strands, class 5
Shielded
No
Voltage
600
Approvals
UR AWM, CE, EAC, RoHS
RoHS
YES
Temperature range
-40°C to +90°C
Outside diameter (OD)
0.098 in

UOM

CSA Certification

UL Certification

YES

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

61470950 Description

SAB 61470950 Halogen Free Cable is part of SABIX® A 147 FRNC product family, and is designed for Control, Power applications. This cable is 20 AWG with 1 conductors, and 20 AWG/1c cable configuration. Featuring Orange color jacket, and bare copper strands, class 5 stranding. It has 0.098 in OD, constructed to support Stationary/Flexible movement type, and rated for 600 volts. This Control, Power cable can operate in -40°C to +90°C temperature range, it is UV resistand, Halogen free, and has following approvals: UR AWM, CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.
