3052750 SAB Data and Sensor Cables

SAB 3052750 LiYY - 20 AWG/27c, multi-conductor signal and control PVC cable with DIN color code
SAB

Part#:3052750

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

LiYY - 20 AWG/27c, multi-conductor signal and control PVC cable with DIN color code

About the manufacturer: SAB is one of the manufacturers that offers Data and Sensor Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 3052750 SAB price in the box on the right side or send a quick quote.

Product Details

  • Outside diameter (OD)
    0.461 in
  • Halogen Free
    NO
  • Gauge
    20 AWG
  • Insulation type
    PVC
  • Voltage
    300
  • UOM
    ft
  • Color
    Grayish Tan
  • Temperature range
    -30°C to +70°C
  • CE Certification
    YES
  • RoHS
    YES
  • CSA Certification
    NO
  • UV Resistant
    NO
  • Application
    Power
  • Shielded
    No
  • Chemical Resistant
    YES
  • Direct Burial
    NO
  • Cable configuration
    20 AWG (≈ 16/32)/27c
  • Movement Type
    Stationary/Flexible
  • Stranding type
    bare copper, fine strands
  • Oil Resistant
    Yes
  • Number of conductors
    27
  • UL Certification
    NO
  • Weight
    68.04 g
  • Approvals
    CE, EAC, RoHS
  • Submersible
    NO

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

3052750 Description

SAB 3052750 Data and Sensor Cable is part of LiYY product family, and is designed for Power applications. This cable is 20 AWG with 27 conductors, and 20 AWG (≈ 16/32)/27c cable configuration. Featuring Grayish Tan color jacket, PVC insulation, and bare copper, fine strands stranding. It has 0.461 in OD, constructed to support Stationary/Flexible movement type, and rated for 300 volts. This Power cable can operate in -30°C to +70°C temperature range, it is chemical resistant, oil resistant, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Power applications.

Related documents 3052750 Specs

3052750 LiYY.pdf
