1272012 SAB High Temperature Cables
Part#:1272012
Manufacturer:SAB
Product Lifecycle:Active
Get a quick Quote!
SC 600 HDTR - 20 AWG/12c, tear resistant high temperature silicone cable, UL, CSA, CE, RoHS
About the manufacturer: SAB is one of the manufacturers that offers High Temperature Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.
Check out the 1272012 SAB price in the box on the right side or send a quick quote.
Product Details
- Oil Resistant No
- Weight 37.65 g
- UV Resistant NO
- Direct Burial NO
- Cable configuration 20 AWG (≈ 16/32)/12c
- CE Certification YES
- Chemical Resistant NO
- UL Certification YES
- Gauge 20 AWG
- Stranding type tinned copper strands, class 5
- Approvals UR AWM, CSA AWM, CE, EAC, RoHS
- RoHS YES
- Outside diameter (OD) 0.378 in
- CSA Certification YES
- Temperature range -40°C to +180°C; +200°C (2000h); +250°C (short-term use)
- Halogen Free YES
- Submersible NO
- Number of conductors 12
- Shielded No
- Movement Type Stationary/Flexible
- Insulation type Besilen (silicone)
- Application Control, Power
- Color Reddish Brown
- Voltage 600
- UOM ft
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
1272012 Description
SAB 1272012 High Temperature Cable is part of SC 600 HDTR product family, and is designed for Control, Power applications. This cable is 20 AWG with 12 conductors, and 20 AWG (≈ 16/32)/12c cable configuration. Featuring Reddish Brown color jacket, Besilen (silicone) insulation, and tinned copper strands, class 5 stranding. It has 0.378 in OD, constructed to support Stationary/Flexible movement type, and rated for 600 volts. This Control, Power cable can operate in -40°C to +180°C; +200°C (2000h); +250°C (short-term use) temperature range, it is Halogen free, and has following approvals: UR AWM, CSA AWM, CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.
Related documents 1272012 Specs
