1231000 SAB High Temperature Cables

Name: 1231000
Brand: SAB

Part#:1231000

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SC 123 - 8 AWG, high temperature hook-up wire with fiberglass braid, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers High Temperature Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 1231000 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Nature
Weight
41.28 g
Chemical Resistant
NO
Oil Resistant
No
UV Resistant
NO
Halogen Free
YES
Submersible
NO
Direct Burial
NO
Movement Type
Stationary/Flexible
Application
Control, Power
Gauge
8 AWG
Number of conductors
1
Cable configuration
8 AWG/1c
Stranding type
tinned copper strands, class 5
Shielded
No
Voltage
300
Approvals
CE, RoHS
RoHS
YES
Temperature range
-40°C to +180°C; +250°C (short-term use)
Outside diameter (OD)
0.287 in

UOM

CSA Certification

UL Certification

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

1231000 Description

SAB 1231000 High Temperature Cable is part of SC 123 product family, and is designed for Control, Power applications. This cable is 8 AWG with 1 conductors, and 8 AWG/1c cable configuration. Featuring Nature color jacket, and tinned copper strands, class 5 stranding. It has 0.287 in OD, constructed to support Stationary/Flexible movement type, and rated for 300 volts. This Control, Power cable can operate in -40°C to +180°C; +250°C (short-term use) temperature range, it is Halogen free, and has following approvals: CE, RoHS. This cable is an excellent choice for Control, Power applications.
