ET-8MG-MIL-1 Red Lion Industrial Automation Components

ET-8MG-MIL-1 on Advantage Electric Supply
Red Lion

Part#:ET-8MG-MIL-1

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion ET-8MG-MIL-1 is an Ethernet Switch designed for surface bulkhead mounting with a metallic case. It operates within an ambient air temperature range of -40 to +75°C and offers a degree of protection rated at IP67. This part of the Sixnet ET series features managed Ethernet switch capabilities, including SNMP v1, v2, v3, RMON, TFTP, STP, RSTP, QoS/CoS/ToS/DS, IGMPv1/v2, VLAN (tag and port-based), HTTP/HTTPS (SSL and TLS), Telnet, SSH, Modbus/TCP, and CLI Interface. It is equipped with 16 MIL-STD-38999 series III connectors supporting 10/100/1000BaseTX for connectivity and requires a supply voltage of 18-30Vdc (24Vdc). The communication protocol used is Ethernet, and it has a connection capacity of 16 ports.

Product Details

  • Primary brand
    Red Lion
  • Supply voltage (DC)
    18-30Vdc (24Vdc)
  • Main function
    Ethernet Switch
  • Communication protocol
    Ethernet
  • Secondary brand
    Sixnet
  • Product series / family name
    Ethernet switches
  • Connection capacity
    16-ports
  • Connection type
    16 x MIL-STD-38999 series III connectors (10/100/1000BaseTX)
  • Equivalent to
    ET8MGMIL1
  • Sub-range name
    Sixnet ET series
  • Material
    Metallic case
  • Functions
    Industrial MIL-STD Gigabit (GbE/GigE) industrial managed Ethernet switch Managed Features SNMP v1; v2; v3; RMON; TFTP; STP; RSTP; QoS/CoS/ToS/DS; IGMPv1/v2; VLAN (tag and port based); HTTP/ HTTPS (SSL and TLS; Telnet; SSH; Modbus/TCP; CLI Interface;
  • Degree of protection
    IP67
  • Mounting mode
    Surface Bulkhead
  • Ambient air temperature for operation
    -40...+75 °C
  • Benefits
    Tough corrosion-proof Aluminium enclosure Rugged reliability in extreme environments
  • Compliant with standard(s)
    CE MIL-STD-810F MIL-STD-461E MIL-STD-1275B IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.1D/w IEEE 802.1p IEEE 802.1Q
  • Order code / Manufacturer SKU
    ET-8MG-MIL-1

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
