E3-16AI8AO-1 Red Lion Industrial Automation Components

E3-16AI8AO-1 on Advantage Electric Supply
Red Lion

Part#:E3-16AI8AO-1

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion E3-16AI8AO-1 is a remote I/O controller designed for mounting plate installation. It operates within an ambient air temperature range of -40 to +75°C. This controller features 16 analog inputs and 8 analog outputs, both supporting 4-20mA DC. It includes built-in self-resetting fuses for protection and is part of the E3 series with built-in I/Os. For connectivity, it offers 2 RJ45 ports for Ethernet, a USB port, and a terminal block for RS-485. The E3-16AI8AO-1 operates on a supply voltage of 10-30Vdc, accommodating both 12Vdc and 24Vdc systems, and supports RS-485 Modbus and Ethernet communication protocols.

Product Details

  • Primary brand
    Red Lion
  • Functions
    Remote I/O controller module
  • Design
    built-in I/Os
  • Order code / Manufacturer SKU
    E3-16AI8AO-1
  • Main function
    Remote I/O controller
  • Sub-range name
    E3 series
  • Mounting mode
    Mounting plate
  • Ambient air temperature for operation
    -40...+75 °C
  • Protection functions
    Built-in self-resetting fuses
  • Product series / family name
    Remote I/Os
  • Communication protocol
    RS-485 Modbus Ethernet
  • Benefits
    Wide variety of I/O configurations Powerful networking capabilities Built-in security for proactively blocking unwanted access RS-485 Port for Connecting Serial Devices to Ethernet network Industrial design supporting deployment in extreme environments Co
  • Supply voltage (DC)
    10-30Vdc (12Vdc / 24Vdc)
  • Analog outputs
    8 x analog outputs (4-20mA DC)
  • Equivalent to
    E316AI8AO1
  • Connection type
    2 x RJ45 ports (Ethernet) USB port Term. blck. (RS-485)
  • Analog inputs
    16 x analog inputs (4-20mA DC)
  • Compliant with standard(s)
    CE MIL-HNDBK-217F2 (MTBF 1 043 917 hours at 40°C) UL Class I Division 2 Group A / B / C / D listed

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
