2-800T NSI Industries Electronic Components

NSI Industries 2-800T Aluminum Double Lug (2) 800-300 MCM (Al/Cu)
NSI Industries

Part#:2-800T

Manufacturer:NSI Industries

Product Lifecycle:Active

In-stock parts: 500

Sep 30, 2024

Aluminum Double Lug (2) 800-300 MCM (Al/Cu)

About the manufacturer: NSI Industries is one of the manufacturers that offers Electronic Components that you can order at Advantage Electric Supply site. We are aware of the necessary conditions for success in the electrical industry and are continuously adapting and growing to reach our objectives, as well as yours. NSi has been supporting electrical contractors in successfully completing difficult projects since 1975, providing products that are favored by professionals.

Check out the 2-800T NSI Industries price in the box on the right side or send a quick quote.

Product Details

  • Prop 65:
    California residents see Prop 65 info here
  • Environmental Conditions:
    90 C
  • Standard:
    cULus
  • Temperature Rating:
    90° C
  • Color:
    Aluminum
  • Voltage Rating:
    600 V
  • Number Of Conductors:
    2
  • Number Of Ports:
    2
  • Wire Size:
    800-300 MCM
  • Type:
    Aluminum Double Lug
  • Number Of Mounting Holes:
    1
  • Bolt Size:
    1/2
  • Finish:
    Aluminum
  • Application:
    Wire Termination
  • Material:
    aluminum

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty
