HP15M4R Mersen Fuses

Name: HP15M4R
Brand: Mersen
Price: 60.49 USD
Availability: BackOrder

Part#:HP15M4R

Manufacturer:Mersen

Category:Fuses

Alt. Part#:0782001504366

Product Lifecycle:Active

Get a quick Quote!

HP15M4R Mersen Photovoltaic fuse gPV 1500VDC IEC 1500VDC UL Size 10x85 4A With Ferrule For Clip

About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the HP15M4R Mersen price in the box on the right side or send a quick quote.

Product Details

Current Rating
4 A
Terminal Type
Ferrule
Type
Photovoltaic Fuses
Weight
0.03 lb
Voltage
1500 VDC
UL Certification
YES
Trip Class
Photovoltaic
Country Of Origin
IN,MX
Fuse Class
Special Purpose Fuses
Sell Pack Weight
0.15 lb
Sell Pack Height
3.25 in
Sell Pack Quantity
5 Each
Sell Pack Length
2.06 in
Sell Pack Width
0.56 in
Product Length
3.34 in
Power Dissipation at Intermediate Current Value
0.79 @ 0.7 In W
Body/Insulating Material
GMG
Product Weight
0.03 lb
Connection/Terminal Material
Tin-Plated Copper
AC Max I.R./Breaking Capacity: I1
50 kA

Connection/Terminal Type

Ferrule

Power Dissipation at Rated Current Value

1.85 W

Product Diameter

0.41 in

Fuse Size

10x85

Rated voltage DC UL

1500 V

Rated voltage DC IEC

1500 V

Fuse Class

Photovoltaic

Speed/Characteristic

gPV

Mounting

Clip

Ampere Rating

4 A

ROHS Compliant

Yes

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

HP15M4R Description

HP15M4R Mersen Photovoltaic fuse gPV 1500VDC IEC 1500VDC UL Size 10x85 4A With Ferrule For Clip

Mersen’s GEN2 of the HP15M photovoltaic (PV) fuse series is designed specifically to meet the severe temperature and current cycling of a PV system. Subjected to stringent cycle testing, the GEN2 provides enhanced reliability. These 1500VDC rated fuses are designed for low minimum breaking capacity capabilities of 1.35 times the fuse rated current value, which allows for safe circuit interruption under typical low fault current conditions. In addition to the standard ferrule terminal, parts are also available with Crimp Cap terminals for in-line fuse applications. The unique wire crimp terminal (CC option) permits solderless wire-to-fuse connection for overmold encapsulation of fuse and wiring. Protect your off-grid or grid tied PV system from unexpected line faults using Mersen’s HelioProtection® fuse line.

*Low fault current interrupting capability

*Durable construction for enhanced system longevity

*Temperature and load cycling capability

*Certified to global standards

*Recommended fuse holders: HP15FHM32A, HP15FHM32B, US15M1HEL

*All photovoltaic applications

*PV string/array level protection

*Combiner box applications

*In-line PV module protection

*Inverters

*Battery charge controllers
