A155F1D0R0-25E Mersen Fuses
Part#:A155F1D0R0-25E
Manufacturer:Mersen
Alt. Part#:782001804596
Product Lifecycle:Active
Get a quick Quote!
A155F1D0R0-25E Mersen - Medium Voltage E-Rated Fuse 15500VAC 25A Ferrule, Series: D0R0 Visual Indicator Amp-Trap®
About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the A155F1D0R0-25E Mersen price in the box on the right side or send a quick quote.
Product Details
- Current Rating 25 A
- Terminal Type Ferrule
- Weight 11.15 lb
- Voltage 15500 VAC
- Trip Class E-Rated
- Country Of Origin MX
- Fuse Class Medium Voltage IEEE Fuses
- Sell Pack Weight 11.71 lb
- Sell Pack Width 4 in
- Sell Pack Height 4 in
- Body/Insulating Material PolyTube
- Sell Pack Length 20.75 in
- Product Diameter 3 in
- Indication System Type Visual Indicator
- Connection/Terminal Type Ferrule
- Product Weight 11.15 lb
- Indication System Yes
- Connection/Terminal Material Silver-Plated Copper
- Sell Pack Quantity 1 Each
- Product Length 18.87 in
- Frequency 50/60 Hz
- Ampere Rating 25 A
- Mounting Clip
- Speed/Characteristic E-Rated
- Rated voltage AC UL 15500 V
- AC Max I.R./Breaking Capacity: I1 50 kA
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
A155F1D0R0-25E Description
A155F1D0R0-25E Mersen - Medium Voltage E-Rated Fuse 15500VAC 25A Ferrule, Series: D0R0 Visual Indicator Amp-Trap®
Mersen fuses for the protection of transformers and distribution lines deliver overload and short circuit protection. These current-limiting fuses will melt at current that can be as low as 1.7 times the fuse current ratings up to its maximum interrupting rating. These fuses are designed to withstand the transformer magnetizing inrush current. They have 2" (size C), 3" (size D) and 2x3" (size DD) inch diameter barrels with ferrules and are mounted in spring reinforced clips.
*Amp-Trap CS-3 and 9F62 series are UL listed for compatibility with UL listed equipment
*Ferrule mounting for standard clips and interchangeability with other brands of fuses
*Current-limiting for superior equipment protection
*Non-venting for silent operation
*Metal embossed catalog number and manufacturing date for lasting identification
*Outdoor usage for the 9F62 and 9F60 type EJO
*Blown-fuse indicator to give positive identification of open fuse: Amp-Trap: 2" Barrel 1 lb tripped force - 0.19 Inch; Amp-Trap: 3" Barrel 2 lb tripped force - 0.50 Inch; 9F60/9F62: 0.125 lb tripped force – 0.20 Inch
*Protection for 12 kV to 15.5 kV transformers or distribution systems.
