83020116 Mersen Electronic Components

Product Details

• Sell Pack Height
  80 mm
• Sell Pack Length
  105 mm
• Sell Pack Width
  45 mm
• Sell Pack Quantity
  1 EACH
• Sell Pack Weight
  0.225 kg
• Product Height
  90 mm
• Replacement Plug L-N
  SP2-40K275V
• Product Length
  70 mm
• Product Width
  36 mm
• Product Weight
  0.225 kg
• Replacement Plug N-PE
  SP2-40K-N
• MCOV L-N
  275 V
• VPR N-G
  700 V
• VPR L-N
  900 V
• MCOV L-G
  275 V
• MCOV N-G
  277 V
• VPR L-G
  1500 V
• Up at In (L-N)
  ≤1.3 kV
• Up at In (N-PE)
  ≤1.5 kV
• Uc (N-PE)
  277 V
Uc (L-N)
275 V
MOV Response Time
25 ns
Max. Back-Up Fuse
125 A gG
Housing Material
PA66 CT1; V-0
Torque Rating
4 N m
Indication System Type
Visual Indicator
Number of Poles
2-Pole
Short Circuit Withstand (ISCCR)
25 kA
Indication System
Yes
Short Circuit Current Rating (SCCR)
50 ... 100 kA
Catalogue No.
STPT2-40K275V-2PG
Following Current (Ifi)
0,1 kA
AC or DC
AC
Max Discharge Current : Imax (8/20)
40kA
System Configuration
TT. TNS
Nominal Discharge Current (In) (8/20)
20kA
Nominal Operating Volt Rating (Un)
230 V
IEC SPD Type
Type 2 / Class II
ROHS Compliant
Yes

Related documents 83020116 Specs
