CDF-07 Mencom Electronic Components

Mencom CDF-07 Standard, CD series, Female Rectangular Insert, size 21.21, 7 pin, 10 amp, Crimp
Mencom

Part#:CDF-07

Manufacturer:Mencom

Product Lifecycle:Active

In-stock parts: 1

Sep 19, 2024

Standard, CD series, Female Rectangular Insert, size 21.21, 7 pin, 10 amp, Crimp

About the manufacturer: Mencom is one of the manufacturers that offers Electronic Components that you can order at Advantage Electric Supply site. Since 1987, Mencom Corporation has been your go-to source for affordable industrial electrical connector solutions. Count on our experienced team to deliver top-quality products with unwavering dedication.

Check out the CDF-07 Mencom price in the box on the right side or send a quick quote.

Product Details

  • Weight (lbs.)
    0.022000
  • Temperature Range in Degrees Celsius
    -40 C to +125 C
  • Lower AWG
    26
  • Cover
    No
  • Termination
    Crimp
  • Amperage Rating
    10
  • Upper AWG
    14
  • Voltage Rating
    600
  • Housing/Insert Type
    Standard
  • Pin Count
    7
  • Gender
    Female
  • Insert Dimension
    21.21
  • Gasket/O-Ring
    No
  • Enclosure Dimension
    21.21
  • ILME Series
    CD
  • Component Type
    Insert
  • Product Type
    Rectangular Connectors

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents CDF-07 Specs

CDF-07 CDF-07.PDF.pdf
CDF-07 CDF-07.DWG.dwg
CDF-07 66.pdf.pdf
CDF-07 CDF-07.DXF.dxf
CDF-07 CDF-07.ZIP.zip

This item can ship within 24h!

Manufacturer warranty

$3.70

Stock:

1

Select Qty:

$3.70

$3.70 each
