118019 Leeson Mechanical Brakes, Clutches & Torque Limiters

Leeson 118019 Electric; 3/4HP; S56C Frame Size; 1800 Sync RPM; 180 Voltage; DC; TENV and XP Enclosure; NEMA Frame Profile; C-Face and Rigid Mounted; Base; 5/8" Shaft Diameter; 3-1/2" Base to Center Height; 16.41" Overall Length; 75.8 Efficiency Full Load
Leeson

Part#:118019

Manufacturer:Leeson

Product Lifecycle:Active

Get a quick Quote!

Electric; 3/4HP; S56C Frame Size; 1800 Sync RPM; 180 Voltage; DC; TENV and XP Enclosure; NEMA Frame Profile; C-Face and Rigid Mounted; Base; 5/8" Shaft Diameter; 3-1/2" Base to Center Height; 16.41" Overall Length; 75.8 Efficiency Full Load

About the manufacturer: Leeson is one of the manufacturers that offers Mechanical Brakes, Clutches & Torque Limiters that you can order at Advantage Electric Supply site. The LEESON® brand provides a diverse selection of AC and DC motors, gearmotors, and variable-speed control solutions tailored for demanding commercial and industrial environments. Whether you need a bulk order for OEM needs or single units for particular uses, LEESON® has the solution for you.

Check out the 118019 Leeson price in the box on the right side or send a quick quote.

Product Details

  • Overall Length
    16.41 Inch | 416.814 Millimeter
  • Shaft Diameter
    0.625 Inch | 15.875 Millimeter
  • Base to Center Height
    3.5 Inch | 88.9 Millimeter
  • Inch - Metric
    Inch
  • Efficiency Full Load
    75.8
  • Weight / LBS
    39
  • Base
    Yes
  • Other Features
    Current Rating 3.3 Ampere | SCR Drive
  • Frame Profile
    NEMA
  • Sync RPM
    1800
  • Mounting Method
    C-Face | Rigid
  • Enclosure
    TENV | XP
  • Brand
    LEESON
  • Voltage
    180
  • Frame Size
    S56C
  • Horse Power
    3/4HP
  • Current
    DC
  • Weight / Kilogram
    17.667
  • UNSPSC
    26101200
  • Minimum Buy Quantity
    N/A

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
