TA2435 ifm Electronic Electronic Components
Part#:TA2435
Manufacturer:ifm Electronic
Category:Electronic Components
Product Lifecycle:Active
Product description
Temperature transmitter, High precision across the entire temperature measurement range, Number of inputs and outputs: Number of analog outputs: 1, Measuring range [°C]: -50...150, Process connection: threaded connection G 1/2, Installation length EL [mm]
Product Details
- Number of analog outputs 1
- Max. load [Ω] 250; ((18...19 V); 19...32 V: 300 Ω)
- Short-circuit protection yes
- Analog current output [mA] 4...20
- Overload protection yes
- Total number of outputs 1
- Output signal analog signal; IO-Link; (configurable)
- Reverse polarity protection yes
- Power-on delay time [s] 1
- Current consumption [mA] < 50
- Operating voltage [V] 18...32 DC; (cULus - Class 2 source required)
- Protection class III
- Pressure rating [bar] 300
- Installation length EL [mm] 100
- Media liquids and gases
- Note on pressure rating sensor When mounted in adapters the specifications of the adapter data sheet apply.
- Measuring element 1 x Pt 1000; (to DIN EN 60751, class A)
- Measuring range [°C] -50...150
- System gold-plated contacts
- Process connection threaded connection G 1/2
- Number of inputs and outputs Number of analog outputs: 1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Manufacturer warranty
