II5837 ifm Electronic Electronic Components

ifm Electronic II5837 Inductive sensor, Robust metal housing for use in harsh industrial environments, Electrical design: PNP, Output function: normally open, Sensing range [mm]: 15, Housing: Threaded type, Dimensions [mm]: M30 x 1.5 / L = 45, System: Increased sensing range
ifm Electronic

Part#:II5837

Manufacturer:ifm Electronic

Product Lifecycle:Active

Get a quick Quote!

Inductive sensor, Robust metal housing for use in harsh industrial environments, Electrical design: PNP, Output function: normally open, Sensing range [mm]: 15, Housing: Threaded type, Dimensions [mm]: M30 x 1.5 / L = 45, System: Increased sensing range

About the manufacturer: ifm Electronic is one of the manufacturers that offers Electronic Components that you can order at Advantage Electric Supply site. Through years of working closely with our customers, we have established ourselves as experts in sensor technology, dedicated to delivering outstanding service. Currently, our company operates in more than 85 countries and employs a team of over 7,000 individuals. Despite our expansion, our dedication to customer satisfaction remains unwavering.

Check out the II5837 ifm Electronic price in the box on the right side or send a quick quote.

Product Details

  • Switching frequency DC [Hz]
    100
  • Permanent current rating of switching output DC [mA]
    250
  • Overload protection
    yes
  • Type of short-circuit protection
    yes (non-latching)
  • Short-circuit protection
    yes
  • Reverse polarity protection
    yes
  • Max. voltage drop switching output DC [V]
    2.5
  • Protection class
    II
  • Operating voltage [V]
    10...36 DC
  • Current consumption [mA]
    15; (24 V)
  • Housing
    Threaded type
  • System
    Increased sensing range
  • Dimensions [mm]
    M30 x 1.5 / L = 45
  • Output function
    normally open
  • Sensing range [mm]
    15
  • Electrical design
    PNP

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents II5837 Specs

II5837 PDF data sheet-1631071540958.pdf
II5837 CAD_STP_100_0088.ZIP-1631071540961.zip
II5837 CAD_DWG_100_0088.ZIP-1631071540988.zip
II5837 CAD_SAT_100_0088.ZIP-1631071540957.zip
II5837 CAD_DXF_100_0088.ZIP-1631071540950.zip
