FAZ-D5/2-RT Eaton Miniature Circuit Breakers (MCBs)

Eaton FAZ-D5/2-RT 277/480 VAC 50/60 Hz, 5 A, 2-Pole, 10/14 kA, 10 to 20 x Rated Current, Ring Tongue Terminal, DIN Rail Mount, Standard Packaging, D-Curve, Current Limiting, Thermal Magnetic
Eaton

Part#:FAZ-D5/2-RT

Manufacturer:Eaton

Product Lifecycle:Active

In-stock parts: 1

Sep 19, 2024

277/480 VAC 50/60 Hz, 5 A, 2-Pole, 10/14 kA, 10 to 20 x Rated Current, Ring Tongue Terminal, DIN Rail Mount, Standard Packaging, D-Curve, Current Limiting, Thermal Magnetic

About the manufacturer: Eaton is one of the manufacturers that offers Miniature Circuit Breakers (MCBs) that you can order at Advantage Electric Supply site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.

Check out the FAZ-D5/2-RT Eaton price in the box on the right side or send a quick quote.

Product Details

  • Terminal Type
    Ring Tongue
  • Trip Curve
    D
  • UL File No.
    E235139
  • UL CCN
    DIVQ
  • SCCR
    10 kA
  • UL Standard
    489
  • Number of Poles
    2 Pole
  • Current Rating
    5 A
  • Mounting:
    DIN Rail
  • Interrupting Rating:
    10 kA
  • Terminal Type:
    Ring Tongue
  • Trip Setting:
    10 to 20 x Rated Current
  • Amps:
    32 A
  • Poles:
    2
  • Wire Size:
    18 to 4/18 to 8 AWG
  • Volts:
    277/480 VAC
  • Size:
    1.39 Inch Width x 2.36 Inch Depth x 4.13 Inch Height
  • Approval:
    UL 489
  • Shipping Weight:
    0.60
  • Series:
    FAZ
  • Shipping Width:
    3.00 In.
  • Shipping Length:
    5.00 In.
  • UPC:
    015081020991
  • Type:
    Current Limiting
  • Shipping Height:
    2.00 In.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents FAZ-D5/2-RT Specs

FAZ-D5/2-RT Catalog:.pdf
FAZ-D5/2-RT Data Sheet:.pdf

This item can ship within 24h!

Manufacturer warranty

$492.50

Stock:

1

Select Qty:

$492.50

$492.50 each

Fast Shipping & Delivery

We deliver nationwide and international

Secure Payment Processing

with money back guarantee

Warranty On All Parts

Manufacturer warranty

Responsive Customer Support

Let us know how we can help!

Need more details?

Feel free to chat with us
