XTOE1P6BCS Eaton Industrial Automation Components

Eaton XTOE1P6BCS Eaton C440 electronic overload relay, XT IEC Electronic Overload Relay, 0.33-1.65A overload range, 45 mm Frame size, NO-NC contact configuration, Direct to contactor mounting, Selectable - 10A, 10, 20, 30 trip type
Eaton

Part#:XTOE1P6BCS

Manufacturer:Eaton

Product Lifecycle:Active

In-stock parts: 3

Sep 19, 2024

Eaton C440 electronic overload relay, XT IEC Electronic Overload Relay, 0.33-1.65A overload range, 45 mm Frame size, NO-NC contact configuration, Direct to contactor mounting, Selectable - 10A, 10, 20, 30 trip type

About the manufacturer: Eaton is one of the manufacturers that offers Industrial Automation Components that you can order at Advantage Electric Supply site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.

Check out the XTOE1P6BCS Eaton price in the box on the right side or send a quick quote.

Product Details

  • Trip Class:
    Class 10A
  • Type:
    Electronic
  • Series:
    XTOE
  • Terminal Type:
    Screw
  • Reset Type:
    Automatic/Manual
  • IEC Size:
    B
  • Enclosure:
    IP20
  • Nema Size:
    00
  • Motor FLA:
    0.33 to 1.65 Amp
  • Auxiliary Contact:
    1NO-1NC
  • Contact Rating:
    690 Volt AC at 50/60 Hertz 5 Amp
  • Mounting:
    Contactor
  • Shipping Height:
    2.00 In.
  • Approval:
    UL
  • Ambient Temperature:
    Compensated
  • UPC:
    786685416397
  • Shipping Length:
    4.00 In.
  • Shipping Width:
    4.00 In.
  • Application:
    3-Phase
  • Shipping Weight:
    0.65 lbs.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents XTOE1P6BCS Specs

XTOE1P6BCS Data Sheet:.pdf
XTOE1P6BCS Specification/Technical:.pdf

This item can ship within 24h!
