FAZ-S3/1 Eaton Supplementary Protectors

Eaton FAZ-S3/1 277/480 VAC 50/60 Hz, 3 A, 1-Pole, 10 kA, 13 to 17 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, S-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
Eaton

Part#:FAZ-S3/1

Manufacturer:Eaton

Product Lifecycle:Active

Get a quick Quote!

277/480 VAC 50/60 Hz, 3 A, 1-Pole, 10 kA, 13 to 17 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, S-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector

About the manufacturer: Eaton is one of the manufacturers that offers Supplementary Protectors that you can order at Advantage Electric Supply site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.

Check out the FAZ-S3/1 Eaton price in the box on the right side or send a quick quote.

Product Details

  • UL File No.
    E177451
  • Terminal Type
    Compression
  • UL CCN
    QVNU2
  • Trip Curve
    S
  • UL Standard
    1077
  • SCCR
    5 kA
  • Current Rating
    3 A
  • Number of Poles
    1 Pole
  • Series:
    FAZ
  • Trip Setting:
    13 to 17 x Rated Current
  • Volts:
    277/480 VAC
  • Terminal Type:
    Line/Load
  • Type:
    Current Limiting
  • Gauge:
    18 to 4/18 to 8 AWG
  • Size:
    0.7 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
  • Poles:
    1
  • Mounting:
    DIN Rail
  • Shipping Width:
    1.00 In.
  • UPC:
    015082786087
  • Interrupting Rating:
    10 Kiloamp
  • Shipping Length:
    4.00 In.
  • Shipping Weight:
    0.25
  • Approval:
    UL 1077
  • Amps:
    3 A
  • Shipping Height:
    3.00 In.
  • Number of poles
    Single-pole
  • Trip Type
    13-17X /n
  • Terminals
    Standard
  • Amperage Rating
    3 A
  • Catalog Notes
    Positioned for highly inductive loads especially in control circuits with coils and light filaments.
  • Product Length/Depth
    1 in
  • Catalog Number
    FAZ-S3/1
  • Warranty
    1 year
  • Product Width
    .75 in
  • Product Weight
    .5 lb
  • EAN
    4015082786083
  • Product Height
    1 in
  • Product Name
    Eaton FAZ supplementary protector
  • Certifications
    CSA Std. C22.2 No.235 UL 1077 IEC 60947-2

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents FAZ-S3/1 Specs

FAZ-S3/1 Datasheet

Manufacturer warranty
