78124 SL005 Alpha Wire Electronic Components
Part#:78124 SL005
Manufacturer:Alpha Wire
Category:Electronic Components
Product Lifecycle:Active
Product description
Alpha EcoCable® Mini Foil Shield Multiconductor Cable - 24 AWG 4 Conductor - Slate - 300V - 100 ft
Product Details
- NOMINAL OD (MM) 3.3528
- TEMPERATURE -40°C to +80°C
- VOLTAGE 300V
- STANDARDS/APPROVALS CE Approved VW-1 UL AWM 21460
- MANUFACTURER PART NUMBER 78124 SL005
- NUMBER OF CONDUCTORS 4
- NOMINAL OD (IN) 0.132
- JACKET COLOR Gray
- JACKET MATERIAL mPPE
- CONDUCTOR STRANDING Stranded
- SHIELDING Foil
- CONDUCTOR MATERIAL Tinned copper
- AWG/GAUGE 24
- SERIES EcoCable Mini
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
