2CCP844001R1829 ABB Control Industrial Automation Components
Part#:2CCP844001R1829
Manufacturer:ABB Control
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
ABB 2CCP844001R1829 is a Miniature Circuit Breaker (MCB) designed specifically for photovoltaic (PV) or solar DC applications. It features screw-clamp connections for secure installation and is rated for a current of 100A with a maximum DC voltage of 1200Vdc. The device has a net height of 106 mm, a net width accommodating 4-poles (4P), and a rated impulse voltage (Uimp) of 8 kV, ensuring it can handle high-voltage spikes. Its rated insulation voltage (Ui) is 1500 V, with a control voltage for DIN rail mounting. The MCB is designed for 10,000 operations, indicating its durability and longevity in solar energy systems.
Product Details
- Secondary brand Stotz
- Main function Miniature Circuit Breaker (MCB)
- Ultimate short circuit current breaking capacity (Icu) 5kA (1200Vdc)
- Size in modules (1 module = 18mm) 6 Module(s)
- Rated impulse voltage (Uimp) 8 kV
- Net Height (mm) 95 mm
- Primary brand ABB
- Poles 4-poles (4P)
- Connection type Screw-clamp connections
- Rated insulation voltage (Ui) 1500 V
- Net Width (mm) 106 mm
- Functions Miniature Circuit Breaker (MCB) for photovoltaic (PV) / solar DC applications
- Rated current 100A
- Mounting mode DIN rail
- Degree of pollution 2
- Product series / family name S800PV series
- Service short circuit current breaking capacity (Ics) 5kA (1200Vdc)
- Mechanical durability (at no load) 10 000 operations
- Net Depth (mm) 82.5 mm
- Tripping curve S
- Rated Voltage (DC) 1200Vdc
- Compliant with standard(s) IEC60947-2 EN60947-2
- Electrical durability (with load) 10 000 operations
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
