Pilz PILZ-328311 is an I/O unit designed for backplane or rackmount installation, featuring digital I/O electronic module capabilities. It supports a range of permitted loads including inductive, capacitive, and resistive, with potential isolation between input and module supply as well as between periphery and module supply, both offering functional insulation and a rated surge voltage of 2500V. The unit operates within an ambient air temperature range of 0 to +55°C and has a net height of 110.8 mm, a width of 12.5 mm, and a depth of 72.5 mm. It is designed with a device code of 000Dh, including 4 ST input bits plus 2 ST status bits, and utilizes plug-in/detachable cage-clamp terminal connections. Classified under the Standard I/O module sub-range, it offers an IP20 degree of protection and requires a supply voltage of 16.8-30Vdc, with 24Vdc nominal. The housing is made of PPE material. Power consumption details include a maximum of 0.16 W for module supply, 0.11 W for an input, 0.15 W with no load, and 0.13 W for voltage output. It can be stored in temperatures ranging from -40 to +70°C. The unit features 2 digital outputs and 4 digital inputs, with outputs supporting 24Vdc at 0.25A and inputs accepting 24Vdc at 3-3.5mA. It includes short-circuit proof potential isolation protection and has a maximum power dissipation/loss of 1 W. Processing times range from 0.005 to 0.3 ms for input signals, with a software filter time of 0 to 25.5 ms.
Quick Quote
Pilz PILZ-328308 is an I/O unit designed as a digital output electronic module with specific capabilities for handling inductive, capacitive, and resistive loads. It features potential isolation between semiconductor output and module supply, ensuring functional insulation with a rated surge voltage of 2500V. This unit is suitable for backplane or rackmount mounting modes and operates within an ambient air temperature range of 0 to +55°C. The device, with a net height of 110.8 mm and a design code of 0019h, includes 4 ST output bits plus 4 ST status bits. It supports a rated current of up to 3.5A max, with a detailed output current range and specific residual and transient pulsed output currents. Connection is facilitated via plug-in/detachable cage-clamp terminal connections. As a standard I/O module, it offers an IP20 degree of protection and requires a supply voltage of 16.8-30Vdc, with a nominal 24Vdc. The housing is made from PPE material, and the unit measures 12.5 mm in width and 72.5 mm in depth. It can be stored in temperatures ranging from -40 to +70°C. The module includes 4 digital outputs, each capable of positive-switching semiconductor outputs at 24Vdc and 2A. Power consumption and dissipation are detailed for various operational states, with a maximum power dissipation of 1.9 W. Processing times for output signals and the internal voltage drop are also specified.
Quick Quote
Pilz PILZ-328303 is an I/O unit designed for backplane or rackmount installation, featuring digital I/O electronic module capabilities. It supports a range of functions including 8 digital inputs and 4 digital outputs, with inputs accepting 24Vdc at 3-3.5mA and outputs supplying 24Vdc at 0.25A. The unit ensures potential isolation between input and module supply as well as between periphery and module supply, both with functional insulation and a rated surge voltage of 2500V. It operates within an ambient air temperature range of 0 to +55°C and can be stored between -40 to +70°C. The device, with a net height of 110.8 mm, width of 12.5 mm, and depth of 72.5 mm, is housed in PPE material and offers an IP20 degree of protection. Connection is facilitated through plug-in/detachable cage-clamp terminal connections. The module's supply voltage ranges from 16.8 to 30Vdc, with a nominal 24Vdc. Power consumption varies, with a maximum of 0.26 W for module supply, 0.11 W for an input, 0.22 W with no load, and 0.13 W for voltage output. Power dissipation/losses can reach up to 1.9 W. Processing times for input signals range from 0.005 to 0.3 ms, with a software filter time of 0 to 25.5 ms. The design includes device code 000Bh with 8 ST input bits plus 4 ST status bits, and it features short-circuit proof protection and potential isolation.
Quick Quote
Pilz PILZ-328301 is an I/O unit designed for backplane or rackmount installation, featuring a digital input electronic module with potential isolation between input and module supply, and functional insulation rated at a surge voltage of 2500V. It operates within an ambient air temperature range of 0 to +55°C and has a net height of 110.8 mm, width of 12.5 mm, and depth of 72.5 mm. This standard I/O module, with a device code of 0008h and 16 ST input bits, utilizes plug-in/detachable cage-clamp terminal connections. It offers an IP20 degree of protection and requires a supply voltage of 16.8-30Vdc, with 24Vdc nominal. The housing is made of PPE material. The module's power consumption is 0.28 W, with a maximum power dissipation/loss of 2.1 W. It supports 16 x digital inputs (24Vdc; 3-3.5mA; type 3 to IEC61131-2; -3...+5Vdc at "0"; +11...+30Vdc at "1") and has a processing time for input signals ranging from 0.005 to 0.3 ms, with a software filter time of 0 to 25.5 ms. The unit is designed for storage in ambient air temperatures ranging from -40 to +70°C.
Quick Quote
Pilz PILZ-773705 is a communications unit designed for expansion and communication purposes, featuring a DeviceNet fieldbus interface suitable for peripheral device types with a station address range of 0-63d. It is engineered for DIN rail mounting, specifically on a 35mmx7.5mm horizontal rail, and operates within an ambient air temperature range of 0 to +60°C. The unit has a net height of 94 mm and is designed to connect to a base unit via a 5-pin plug-in connector. As part of the Communication module sub-range, it measures 27mm in width, offers an IP20 degree of protection, and requires a 24Vdc external supply for DeviceNet and a 4.9-5.1Vdc (5Vdc nom.) module supply via the base unit. Constructed with a PPO bottom housing and an ABS front housing, it has a rated voltage of 500Vac for DeviceNet testing, a net width of 22.5 mm, and supports the DeviceNet communication protocol. The power consumption is 1 W from the supply via the base unit for DeviceNet and 0.75 W for the module, with a net depth of 122 mm. It is designed for storage in ambient air temperatures ranging from -25 to +70°C and features galvanic isolation protection functions. The rated insulation voltage (Ui) is 30 V, and it supports transmission rates of 125kBit/s, 250kBit/s, and 500kBit/s on DeviceNet, with a time delay of 20ms for supply interruption before de-energization.
Quick Quote
Pilz PILZ-328072 is a communications unit designed for Ethernet/IP applications, featuring a Manufacturer ID of 181 and a Product ID of 256. It operates as an adapter device type with a maximum of 1 I/O connection for Ethernet/IP and up to 2 I/O connections for CIP safety, both certified by ODVA. The unit provides potential isolation with functional insulation between various power supplies and connections, ensuring a rated surge voltage of 2500V for most isolations and 1500V between the module supply and Ethernet/IP. It supports DIN rail mounting and can operate within an ambient air temperature range of 0 to +60°C. The unit has a net height of 110.1 mm, a width of 64.1 mm, and a depth of 94.7 mm, with a design that includes a microSD device code C006h for standard/safety units. It has a rated current of 8A for the peripheral supply and utilizes plug-in/detachable spring-loaded terminal connections. The communication module falls under the IP20 protection degree and requires a supply voltage of 16.8-30Vdc, with a nominal 24Vdc for both module and peripheral supply. Constructed with a PPE housing, it supports a communication protocol of Ethernet/IP and has a memory capacity of 508Byte for Ethernet/IP data length and 18Byte for CIP safety data length. The unit accommodates a wire cross-section of 0.15 to 1.5mm2 (26AWG to 14AWG conductors). It is designed for storage in ambient air temperatures ranging from -40 to +70°C and has a rated power output for various operational and no-load conditions. The response time for the Ethernet/IP adapter ranges from 1-3200ms, with a transmission rate of 100MBit/s, and the processing time for CIP safety ranges from 6-3200 ms.
Quick Quote
Pilz PILZ-772035 is a communications unit designed as an expansion/communication module with EtherCAT and CANopen fieldbus interfaces. It features peripheral device type functionality and logs CANopen over EtherCAT with potential isolation between the fieldbus and module voltage, ensuring functional insulation with a rated surge voltage of 500V. This unit is suitable for DIN rail mounting, specifically on a 35mmx7.5mm horizontal rail, and operates within an ambient air temperature range of 0 to +60°C without forced convection in the control cabinet, and up to +55°C with forced convection off. The unit has a net height of 100 mm, a width of 22.5 mm, and a depth of 115 mm. Connection is facilitated through an RJ45 connector plug-in/detachable screw or spring-loaded terminals, supporting 2 points per spring-loaded connection with a 9mm stripping length. It falls under the communication module sub-range, with dimensions of W27mm and a degree of protection rated at IP20. The supply voltage requirement is 19.2-30Vdc, with a nominal 24Vdc. The housing is made of PC material. It supports a communication protocol of EtherCAT CANopen and accommodates a wire cross-section ranging from 0.25 to 2.5mm2 for various connection types. The power consumption of the module supply is 1.5 W. It is designed for storage in ambient air temperatures ranging from -25 to +70°C and includes protection functions such as galvanic isolation and potential isolation. The rated insulation voltage (Ui) is 30 V, with a speed of 100MBit/s for EtherCAT transmission and a time delay of 20ms for supply interruption before de-energization.
Quick Quote
Pilz PILZ-328071 is an I/O unit designed for digital output with electronic patch terminal module capabilities. It supports a range of permitted loads including inductive, capacitive, and resistive, with potential isolation between periphery supply and module supply, ensuring functional insulation and a rated surge voltage of 2500V. This unit operates within an ambient air temperature range of 0 to +60°C and has a net height of 110.8 mm. It features a device code of 0005h with 16 ST status bits and utilizes plug-in/detachable cage-clamp terminal connections. As part of the Patch term. sub-range, it offers an IP20 degree of protection and requires a supply voltage of 16.8-30Vdc, with 24Vdc nominal. The housing is made from PC material, and the unit measures 12.5 mm in width and 72.5 mm in depth. It has a low power consumption, with module supply at 0.28 W, periphery supply module power consumption with no load at 0.53 W, and maximum power consumption of voltage output at 0.055 W. The unit can be stored in temperatures ranging from -40 to +70°C. It features 16 digital outputs (voltage output; 24Vdc; 0.5A) and includes protection functions such as short-circuit proof, potential isolation, and overload proof, with a maximum power dissipation/losses of 1.7 W.
Quick Quote
Pilz PILZ-773733 is a Safety I/O unit designed for DIN rail mounting, compatible with both 35mmx7.5mm top hat and 27mm recess width rails. It operates within an ambient air temperature range of 0 to +60°C and has a net height of 94 mm. This unit features various connection types including screw terminal connections, spring-loaded terminal connections, and an 8-pin RJ45 female connector for incremental encoders, with stripping lengths of 7mm for screw connections and 9mm for spring-loaded connections. As part of the Safe I/O module sub-range, it offers a degree of protection of IP20 and requires a supply voltage of 20.4-28.8Vdc (24Vdc nominal) or 4.9-5.1Vdc (5Vdc nominal; module supply via base unit). The frequency ranges for input are 0-3kHz for proximity switches and 0-500kHz for incremental encoders, with monitoring frequencies adjusted for hysteresis. The unit is constructed from PPO for the bottom housing and ABS for the front housing, measures 45 mm in width and 121 mm in depth, and supports wire cross-sections ranging from 0.25 to 1.5mm2 / 24AWG to 16AWG for various connections. Power consumption is 1 W from supply via the base module. It is designed for storage in ambient air temperatures of -25 to +70°C and features protection functions including galvanic isolation and overload proof (-30 to +30V). The rated insulation voltage is 30 V. It includes 4 digital inputs for proximity switches and 2 digital inputs for incremental encoders, with specific signal level requirements. Time delay and angle phase position for differential signals are configurable, ensuring precise control and integration into safety systems.
Quick Quote
Pilz PILZ-773732 is a communications unit designed for expansion and communication tasks within industrial automation systems. It features a CANopen fieldbus interface, supporting the CiA DS-301 V4.02 protocol, making it suitable for connecting to a base unit as a peripheral device. The unit allows for station addresses ranging from 0 to 99d and is designed for DIN rail mounting, compatible with 35mmx7.5mm rails, positioned horizontally. It operates within an ambient air temperature range of 0 to +60°C and has a net height of 94 mm. The connection to the base unit is facilitated through a 9-pin D-sub male connector. Classified under the communication module sub-range, it measures 27mm in width, offers an IP20 degree of protection, and requires a supply voltage of 20.4-28.8Vdc (24Vdc nominal) or 4.9-5.1Vdc (5Vdc nominal; module supply via base unit). The housing is made from PPO for the bottom and ABS for the front, ensuring compatibility with various industrial environments. It has a rated voltage of 500Vac for CANopen, a net width of 22.5 mm, and consumes 1W of power from the supply provided via the base unit. The net depth is 119 mm, and it can be stored in temperatures ranging from -25 to +70°C. For protection, it features galvanic isolation, a rated insulation voltage (Ui) of 30 V, and supports multiple transmission rates for CANopen from 10kBit/s up to 1MBit/s, with a time delay of 20ms for supply interruption before de-energization.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| PILZ-328311 Pilz PILZ-328311 is an I/O unit designed for backplane or rackmount installation, featuring digital I/O electronic module capabilities. It supports a range of permitted loads including inductive, capacitive, and resistive, with potential isolation between input and module supply as well as between periphery and module supply, both offering functional insulation and a rated surge voltage of 2500V. The unit operates within an ambient air temperature range of 0 to +55°C and has a net height of 110.8 mm, a width of 12.5 mm, and a depth of 72.5 mm. It is designed with a device code of 000Dh, including 4 ST input bits plus 2 ST status bits, and utilizes plug-in/detachable cage-clamp terminal connections. Classified under the Standard I/O module sub-range, it offers an IP20 degree of protection and requires a supply voltage of 16.8-30Vdc, with 24Vdc nominal. The housing is made of PPE material. Power consumption details include a maximum of 0.16 W for module supply, 0.11 W for an input, 0.15 W with no load, and 0.13 W for voltage output. It can be stored in temperatures ranging from -40 to +70°C. The unit features 2 digital outputs and 4 digital inputs, with outputs supporting 24Vdc at 0.25A and inputs accepting 24Vdc at 3-3.5mA. It includes short-circuit proof potential isolation protection and has a maximum power dissipation/loss of 1 W. Processing times range from 0.005 to 0.3 ms for input signals, with a software filter time of 0 to 25.5 ms. | Pilz | Quick Quote | ||
| PILZ-328308 Pilz PILZ-328308 is an I/O unit designed as a digital output electronic module with specific capabilities for handling inductive, capacitive, and resistive loads. It features potential isolation between semiconductor output and module supply, ensuring functional insulation with a rated surge voltage of 2500V. This unit is suitable for backplane or rackmount mounting modes and operates within an ambient air temperature range of 0 to +55°C. The device, with a net height of 110.8 mm and a design code of 0019h, includes 4 ST output bits plus 4 ST status bits. It supports a rated current of up to 3.5A max, with a detailed output current range and specific residual and transient pulsed output currents. Connection is facilitated via plug-in/detachable cage-clamp terminal connections. As a standard I/O module, it offers an IP20 degree of protection and requires a supply voltage of 16.8-30Vdc, with a nominal 24Vdc. The housing is made from PPE material, and the unit measures 12.5 mm in width and 72.5 mm in depth. It can be stored in temperatures ranging from -40 to +70°C. The module includes 4 digital outputs, each capable of positive-switching semiconductor outputs at 24Vdc and 2A. Power consumption and dissipation are detailed for various operational states, with a maximum power dissipation of 1.9 W. Processing times for output signals and the internal voltage drop are also specified. | Pilz | Quick Quote | ||
| PILZ-328303 Pilz PILZ-328303 is an I/O unit designed for backplane or rackmount installation, featuring digital I/O electronic module capabilities. It supports a range of functions including 8 digital inputs and 4 digital outputs, with inputs accepting 24Vdc at 3-3.5mA and outputs supplying 24Vdc at 0.25A. The unit ensures potential isolation between input and module supply as well as between periphery and module supply, both with functional insulation and a rated surge voltage of 2500V. It operates within an ambient air temperature range of 0 to +55°C and can be stored between -40 to +70°C. The device, with a net height of 110.8 mm, width of 12.5 mm, and depth of 72.5 mm, is housed in PPE material and offers an IP20 degree of protection. Connection is facilitated through plug-in/detachable cage-clamp terminal connections. The module's supply voltage ranges from 16.8 to 30Vdc, with a nominal 24Vdc. Power consumption varies, with a maximum of 0.26 W for module supply, 0.11 W for an input, 0.22 W with no load, and 0.13 W for voltage output. Power dissipation/losses can reach up to 1.9 W. Processing times for input signals range from 0.005 to 0.3 ms, with a software filter time of 0 to 25.5 ms. The design includes device code 000Bh with 8 ST input bits plus 4 ST status bits, and it features short-circuit proof protection and potential isolation. | Pilz | Quick Quote | ||
| PILZ-328301 Pilz PILZ-328301 is an I/O unit designed for backplane or rackmount installation, featuring a digital input electronic module with potential isolation between input and module supply, and functional insulation rated at a surge voltage of 2500V. It operates within an ambient air temperature range of 0 to +55°C and has a net height of 110.8 mm, width of 12.5 mm, and depth of 72.5 mm. This standard I/O module, with a device code of 0008h and 16 ST input bits, utilizes plug-in/detachable cage-clamp terminal connections. It offers an IP20 degree of protection and requires a supply voltage of 16.8-30Vdc, with 24Vdc nominal. The housing is made of PPE material. The module's power consumption is 0.28 W, with a maximum power dissipation/loss of 2.1 W. It supports 16 x digital inputs (24Vdc; 3-3.5mA; type 3 to IEC61131-2; -3...+5Vdc at "0"; +11...+30Vdc at "1") and has a processing time for input signals ranging from 0.005 to 0.3 ms, with a software filter time of 0 to 25.5 ms. The unit is designed for storage in ambient air temperatures ranging from -40 to +70°C. | Pilz | Quick Quote | ||
| PILZ-773705 Pilz PILZ-773705 is a communications unit designed for expansion and communication purposes, featuring a DeviceNet fieldbus interface suitable for peripheral device types with a station address range of 0-63d. It is engineered for DIN rail mounting, specifically on a 35mmx7.5mm horizontal rail, and operates within an ambient air temperature range of 0 to +60°C. The unit has a net height of 94 mm and is designed to connect to a base unit via a 5-pin plug-in connector. As part of the Communication module sub-range, it measures 27mm in width, offers an IP20 degree of protection, and requires a 24Vdc external supply for DeviceNet and a 4.9-5.1Vdc (5Vdc nom.) module supply via the base unit. Constructed with a PPO bottom housing and an ABS front housing, it has a rated voltage of 500Vac for DeviceNet testing, a net width of 22.5 mm, and supports the DeviceNet communication protocol. The power consumption is 1 W from the supply via the base unit for DeviceNet and 0.75 W for the module, with a net depth of 122 mm. It is designed for storage in ambient air temperatures ranging from -25 to +70°C and features galvanic isolation protection functions. The rated insulation voltage (Ui) is 30 V, and it supports transmission rates of 125kBit/s, 250kBit/s, and 500kBit/s on DeviceNet, with a time delay of 20ms for supply interruption before de-energization. | Pilz | Quick Quote | ||
| PILZ-328072 Pilz PILZ-328072 is a communications unit designed for Ethernet/IP applications, featuring a Manufacturer ID of 181 and a Product ID of 256. It operates as an adapter device type with a maximum of 1 I/O connection for Ethernet/IP and up to 2 I/O connections for CIP safety, both certified by ODVA. The unit provides potential isolation with functional insulation between various power supplies and connections, ensuring a rated surge voltage of 2500V for most isolations and 1500V between the module supply and Ethernet/IP. It supports DIN rail mounting and can operate within an ambient air temperature range of 0 to +60°C. The unit has a net height of 110.1 mm, a width of 64.1 mm, and a depth of 94.7 mm, with a design that includes a microSD device code C006h for standard/safety units. It has a rated current of 8A for the peripheral supply and utilizes plug-in/detachable spring-loaded terminal connections. The communication module falls under the IP20 protection degree and requires a supply voltage of 16.8-30Vdc, with a nominal 24Vdc for both module and peripheral supply. Constructed with a PPE housing, it supports a communication protocol of Ethernet/IP and has a memory capacity of 508Byte for Ethernet/IP data length and 18Byte for CIP safety data length. The unit accommodates a wire cross-section of 0.15 to 1.5mm2 (26AWG to 14AWG conductors). It is designed for storage in ambient air temperatures ranging from -40 to +70°C and has a rated power output for various operational and no-load conditions. The response time for the Ethernet/IP adapter ranges from 1-3200ms, with a transmission rate of 100MBit/s, and the processing time for CIP safety ranges from 6-3200 ms. | Pilz | Quick Quote | ||
| PILZ-772035 Pilz PILZ-772035 is a communications unit designed as an expansion/communication module with EtherCAT and CANopen fieldbus interfaces. It features peripheral device type functionality and logs CANopen over EtherCAT with potential isolation between the fieldbus and module voltage, ensuring functional insulation with a rated surge voltage of 500V. This unit is suitable for DIN rail mounting, specifically on a 35mmx7.5mm horizontal rail, and operates within an ambient air temperature range of 0 to +60°C without forced convection in the control cabinet, and up to +55°C with forced convection off. The unit has a net height of 100 mm, a width of 22.5 mm, and a depth of 115 mm. Connection is facilitated through an RJ45 connector plug-in/detachable screw or spring-loaded terminals, supporting 2 points per spring-loaded connection with a 9mm stripping length. It falls under the communication module sub-range, with dimensions of W27mm and a degree of protection rated at IP20. The supply voltage requirement is 19.2-30Vdc, with a nominal 24Vdc. The housing is made of PC material. It supports a communication protocol of EtherCAT CANopen and accommodates a wire cross-section ranging from 0.25 to 2.5mm2 for various connection types. The power consumption of the module supply is 1.5 W. It is designed for storage in ambient air temperatures ranging from -25 to +70°C and includes protection functions such as galvanic isolation and potential isolation. The rated insulation voltage (Ui) is 30 V, with a speed of 100MBit/s for EtherCAT transmission and a time delay of 20ms for supply interruption before de-energization. | Pilz | Quick Quote | ||
| PILZ-328071 Pilz PILZ-328071 is an I/O unit designed for digital output with electronic patch terminal module capabilities. It supports a range of permitted loads including inductive, capacitive, and resistive, with potential isolation between periphery supply and module supply, ensuring functional insulation and a rated surge voltage of 2500V. This unit operates within an ambient air temperature range of 0 to +60°C and has a net height of 110.8 mm. It features a device code of 0005h with 16 ST status bits and utilizes plug-in/detachable cage-clamp terminal connections. As part of the Patch term. sub-range, it offers an IP20 degree of protection and requires a supply voltage of 16.8-30Vdc, with 24Vdc nominal. The housing is made from PC material, and the unit measures 12.5 mm in width and 72.5 mm in depth. It has a low power consumption, with module supply at 0.28 W, periphery supply module power consumption with no load at 0.53 W, and maximum power consumption of voltage output at 0.055 W. The unit can be stored in temperatures ranging from -40 to +70°C. It features 16 digital outputs (voltage output; 24Vdc; 0.5A) and includes protection functions such as short-circuit proof, potential isolation, and overload proof, with a maximum power dissipation/losses of 1.7 W. | Pilz | Quick Quote | ||
| PILZ-773733 Pilz PILZ-773733 is a Safety I/O unit designed for DIN rail mounting, compatible with both 35mmx7.5mm top hat and 27mm recess width rails. It operates within an ambient air temperature range of 0 to +60°C and has a net height of 94 mm. This unit features various connection types including screw terminal connections, spring-loaded terminal connections, and an 8-pin RJ45 female connector for incremental encoders, with stripping lengths of 7mm for screw connections and 9mm for spring-loaded connections. As part of the Safe I/O module sub-range, it offers a degree of protection of IP20 and requires a supply voltage of 20.4-28.8Vdc (24Vdc nominal) or 4.9-5.1Vdc (5Vdc nominal; module supply via base unit). The frequency ranges for input are 0-3kHz for proximity switches and 0-500kHz for incremental encoders, with monitoring frequencies adjusted for hysteresis. The unit is constructed from PPO for the bottom housing and ABS for the front housing, measures 45 mm in width and 121 mm in depth, and supports wire cross-sections ranging from 0.25 to 1.5mm2 / 24AWG to 16AWG for various connections. Power consumption is 1 W from supply via the base module. It is designed for storage in ambient air temperatures of -25 to +70°C and features protection functions including galvanic isolation and overload proof (-30 to +30V). The rated insulation voltage is 30 V. It includes 4 digital inputs for proximity switches and 2 digital inputs for incremental encoders, with specific signal level requirements. Time delay and angle phase position for differential signals are configurable, ensuring precise control and integration into safety systems. | Pilz | Quick Quote | ||
| PILZ-773732 Pilz PILZ-773732 is a communications unit designed for expansion and communication tasks within industrial automation systems. It features a CANopen fieldbus interface, supporting the CiA DS-301 V4.02 protocol, making it suitable for connecting to a base unit as a peripheral device. The unit allows for station addresses ranging from 0 to 99d and is designed for DIN rail mounting, compatible with 35mmx7.5mm rails, positioned horizontally. It operates within an ambient air temperature range of 0 to +60°C and has a net height of 94 mm. The connection to the base unit is facilitated through a 9-pin D-sub male connector. Classified under the communication module sub-range, it measures 27mm in width, offers an IP20 degree of protection, and requires a supply voltage of 20.4-28.8Vdc (24Vdc nominal) or 4.9-5.1Vdc (5Vdc nominal; module supply via base unit). The housing is made from PPO for the bottom and ABS for the front, ensuring compatibility with various industrial environments. It has a rated voltage of 500Vac for CANopen, a net width of 22.5 mm, and consumes 1W of power from the supply provided via the base unit. The net depth is 119 mm, and it can be stored in temperatures ranging from -25 to +70°C. For protection, it features galvanic isolation, a rated insulation voltage (Ui) of 30 V, and supports multiple transmission rates for CANopen from 10kBit/s up to 1MBit/s, with a time delay of 20ms for supply interruption before de-energization. | Pilz | Quick Quote | ||
