12518ET3E444TC-W22 WEG AC Motors
Part#:12518ET3E444TC-W22
Manufacturer:WEG
Category:AC Motors
Alt. Part#:7909018220406
Product Lifecycle:Active
Get a quick Quote!
W22 NEMA Premium Efficiency 125 HP 4P 444/5TC 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted
Check out the 12518ET3E444TC-W22 WEG price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 125 HP
- Rated Speed 1785 rpm
- Flange Type C
- Terminal box¹ Left position
- Synchronous speed 1800 rpm
- Noise level² 73.0 dB(A)
- Number of poles 4
- Flange C
- Voltage 230/460//380 V
- Output rating 125 HP
- Ambient temperature -20°C to +40°C
- Standard NEMA MG-1
- Approx. weight³ 1564 lb
- Degree of Protection IP55
- Rotation¹ Both (CW and CCW)
- Enclosure IC411 - TEFC
- Duty Cycle Cont.(S1)
- Locked rotor time 48s (cold) 27s (hot)
- Starting Method Direct On Line
- Mounting F-1
- Altitude 1000 m.a.s.l.
- Temperature rise 80 K
- Service factor 1.15
- No load current 92.0/46.0 A
- Locked rotor torque 200 %
- Design B
- Moment of inertia (J) 57.2 sq.ft.lb
- Breakdown torque 229 %
- Insulation Class F
- Rated torque 368 ft.lb
- Rated speed 1785 rpm
- LRC 6.5x(Code G)
- Frequency 60 Hz
- Output 125 HP
- Number of Poles 4
- Rated current 279/139 A
- Slip 0.83 %
- L. R. Amperes 1811/905 A
- Rated voltage 230/460 V
- Frame 444/5TC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents 12518ET3E444TC-W22 Specs
