02509ET3E326T-W22 WEG AC Motors

02509ET3E326T-W22 on Advantage Electric Supply
WEG

Part#:02509ET3E326T-W22

Manufacturer:WEG

Category:AC Motors

Alt. Part#:7891327160200

Product Lifecycle:Active

Get a quick Quote!

W22 NEMA Premium Efficiency 25 HP 8P 324/6T 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Check out the 02509ET3E326T-W22 WEG price in the box on the right side or send a quick quote.

Product Details

  • Number of Poles
    8 Pole
  • Voltage
    230/460 V
  • Output Rating
    25 HP
  • Rated Speed
    880 rpm
  • Flange Type
    Without
  • Standard
    NEMA MG-1
  • Flange
    Without
  • Terminal box¹
    Left position
  • Number of poles
    8
  • Synchronous speed
    900 rpm
  • Voltage
    230/460//380 V
  • Output rating
    25 HP
  • Altitude
    1000 m.a.s.l.
  • Approx. weight³
    555 lb
  • Noise level²
    56.0 dB(A)
  • Rotation¹
    Both (CW and CCW)
  • Mounting
    F-1
  • Enclosure
    IC411 - TEFC
  • Degree of Protection
    IP55
  • Starting Method
    Direct On Line
  • Ambient temperature
    -20°C to +40°C
  • Duty Cycle
    Cont.(S1)
  • Service factor
    1.25
  • Temperature rise
    80 K
  • Locked rotor torque
    200 %
  • Breakdown torque
    229 %
  • Locked rotor time
    41s (cold) 23s (hot)
  • Insulation Class
    F
  • Moment of inertia (J)
    11.9 sq.ft.lb
  • No load current
    40.0/20.0 A
  • Design
    B
  • Rated torque
    149 ft.lb
  • LRC
    5.2x(Code G)
  • Number of Poles
    8
  • Frame
    324/6T
  • Rated speed
    880 rpm
  • Rated current
    71.8/35.9 A
  • L. R. Amperes
    373/187 A
  • Slip
    2.22 %
  • Output
    25 HP (18.5 kW)
  • Rated voltage
    230/460 V
  • Frequency
    60 Hz

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents 02509ET3E326T-W22 Specs

02509ET3E326T-W22 Datasheet.pdf
02509ET3E326T-W22 Drawings.pdf
