.5036ES1BW56C-S WEG AC Motors

WEG .5036ES1BW56C-S Rolled Steel 0.5 HP 2P W56C 1Ph 115/208-230 V 60 Hz IC411 - TEFC - Foot-mounted
WEG

Part#:.5036ES1BW56C-S

Manufacturer:WEG

Alt. Part#:7909322525457

Product Lifecycle:Active

Get a quick Quote!

Rolled Steel 0.5 HP 2P W56C 1Ph 115/208-230 V 60 Hz IC411 - TEFC - Foot-mounted

Check out the .5036ES1BW56C-S WEG price in the box on the right side or send a quick quote.

Product Details

  • Number of Poles
    2 Pole
  • Voltage
    115/208-230 V
  • Output Rating
    0.5 HP
  • Rated Speed
    3500 rpm
  • Flange Type
    C
  • Synchronous speed
    3600 rpm
  • Terminal box¹
    Left position
  • Number of poles
    2
  • Output rating
    0.5 HP
  • Flange
    C
  • Standard
    NEMA MG-1
  • Voltage
    115/208-230 V
  • Approx. weight³
    21.5 lb
  • Noise level²
    66.0 dB(A)
  • Rotation¹
    Both (CW and CCW)
  • Mounting
    F-1
  • Enclosure
    IC411 - TEFC
  • Starting Method
    Direct On Line
  • Altitude
    1000 m.a.s.l.
  • Ambient temperature
    -20°C to +40°C
  • Service factor
    1.15 (1.00 @ 208V)
  • Duty Cycle
    Cont.(S1)
  • Degree of Protection
    IP55
  • Locked rotor time
    12s (cold) 7s (hot)
  • Breakdown torque
    300 %
  • Locked rotor torque
    290 %
  • Temperature rise
    80 K
  • Moment of inertia (J)
    0.0233 sq.ft.lb
  • Rated torque
    0.750 ft.lb
  • Insulation Class
    F
  • No load current
    4.80/2.07-2.40 A
  • Design
    N
  • LRC
    8.0x(Code P)
  • Rated voltage
    115/208-230 V
  • Output
    0.5 HP (0.37 kW)
  • L. R. Amperes
    56.0/31.0-28.0 A
  • Slip
    2.78 %
  • Rated current
    7.00/3.87-3.50 A
  • Frame
    W56C
  • Rated speed
    3500 rpm
  • Frequency
    60 Hz
  • Number of Poles
    2

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
