SLB440-ER-3-LST Schmersal Safety Light Curtains

Product Details

• Length of cable, maximum
  100 m
• Versions
  p-type
• Output current, (fail-safe output), maximum
  0.2 A
• Electrical power consumption of the transmitter, maximum
  5 W
• Electrical power consumption of the receiver, maximum
  5 W
• Protection rating
  III
• Storage and transport temperature, minimum
  -30 °C
• Switching voltage OSSD, HIGH signal
  24 V
• Voltage type
  DC (direct current)
• Storage and transport temperature, maximum
  +70 °C
• Ambient temperature, maximum
  +50 °C
• Length
  33 mm
• Ambient temperature, minimum
  -30 °C
• Terminal, Connector, Transmitter
  Cable with connector plug M12, 4-pole
• Height
  72 mm
• Width
  27.8 mm
• Degree of protection
  IP67 to EN 60529
• Terminal connector, Recipient
  Cable with connector plug M12, 5-pole
• Wave length of the sensor
  880 nm
• Range, protection field, maximum
  15,000 mm
Restart interlock (manual reset)
Yes
Reaction time, maximum
22 ms
Integral System Diagnostics, status
Yes
Detection ability for test bodies at v = 1.6 m/s
40 mm
Standards
EN 61496-1, EN 61496-2
Coding, light barrier beam
3
Range, protection field, minimum
300 mm
Reaction time, minimum
7 ms
Beam coding available
Yes
Number of fail-safe digital outputs
2
Number of beams
1
Integral System Diagnostics
Yes
Enclosure material
Aluminium
Gross weight
180 g
