95551612 SAB Tray Cables
Part#:95551612
Manufacturer:SAB
Product Lifecycle:Active
Get a quick Quote!
TR 600 Plus - 16 AWG/12c, UV and oil resistant flexible exposed run tray cable with reduced O.D., UL, CSA, CE, RoHS
About the manufacturer: SAB is one of the manufacturers that offers Tray Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.
Check out the 95551612 SAB price in the box on the right side or send a quick quote.
Product Details
- Chemical Resistant NO
- UV Resistant YES
- Direct Burial YES
- Cable configuration 16 AWG/12c
- CE Certification YES
- Weight 120.66 g
- RoHS YES
- UL Certification YES
- CSA Certification YES
- Gauge 16 AWG
- Shielded No
- Approvals UL TC-ER, UL MTW, UL WTTC, UR AWM, CSA CIC, CSA AWM, CE, RoHS
- UOM ft
- Application Control, Power
- Insulation type PVC/Nylon
- Voltage 600
- Halogen Free NO
- Movement Type Stationary/Flexible
- Stranding type bare copper strands, class 5
- Outside diameter (OD) 0.496 in
- Oil Resistant Yes
- Number of conductors 12
- Submersible NO
- Color Black
- Temperature range -25°C to +105°C
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
95551612 Description
SAB 95551612 Tray Cable is part of TR 600 Plus product family, and is designed for Control, Power applications. This cable is 16 AWG with 12 conductors, and 16 AWG/12c cable configuration. Featuring Black color jacket, PVC/Nylon insulation, and bare copper strands, class 5 stranding. It has 0.496 in OD, constructed to support Stationary/Flexible movement type, and rated for 600 volts. This Control, Power cable can operate in -25°C to +105°C temperature range, it is oil resistant, UV resistand, rated for direct burial, and has following approvals: UL TC-ER, UL MTW, UL WTTC, UR AWM, CSA CIC, CSA AWM, CE, RoHS. This cable is an excellent choice for Control, Power applications.
