8390122 SAB Servo Motor Cables

Name: 8390122
Brand: SAB

SAB 8390122 SL 839 C -22 AWG/12c, composite PUR transmission cable with overall tinned copper screen, UL, RoHS

Part#:8390122

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SL 839 C -22 AWG/12c, composite PUR transmission cable with overall tinned copper screen, UL, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Servo Motor Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 8390122 SAB price in the box on the right side or send a quick quote.

Product Details

Submersible
NO
UV Resistant
YES
Stranding type
bare copper, fine strands
UOM
ft
Halogen Free
YES
Gauge
22 AWG
Chemical Resistant
YES
Color
Green
CSA Certification
NO
Cable configuration
22 AWG/12c
Shielded
Yes
RoHS
YES
Movement Type
Stationary/Flexible
Approvals
UR AWM, EAC, RoHS
Weight
19.96 g
Direct Burial
NO
Insulation type
Special Polymer
Oil Resistant
Yes
Outside diameter (OD)
0.264 in
Number of conductors
12

CE Certification

Application

Control, Data, Motor & Drives

Voltage

Temperature range

-40°C to +80°C

UL Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

8390122 Description

SAB 8390122 Servo Motor Cable is part of SL 839 C product family, and is designed for Control, Data, Motor & Drives applications. This cable is 22 AWG with 12 conductors, and shielded 22 AWG/12c cable configuration. Featuring Green color jacket, Special Polymer insulation, and bare copper, fine strands stranding. It has 0.264 in OD, constructed to support Stationary/Flexible movement type, and rated for 30 volts. This Control, Data, Motor & Drives cable can operate in -40°C to +80°C temperature range, it is chemical resistant, oil resistant, UV resistand, Halogen free, and has following approvals: UR AWM, EAC, RoHS. This cable is an excellent choice for Control, Data, Motor & Drives applications.
