67452734 SAB Halogen Free Cables

Name: 67452734
Brand: SAB

Part#:67452734

Manufacturer:SAB

Category:Halogen Free Cables

Product Lifecycle:Active

Get a quick Quote!

SABIX SD 745 C FRNC C1 TP - 22 AWG/27pr, shielded halogen-free flame retardant continuous flex data cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 67452734 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Black
Weight
140.50 g
Chemical Resistant
NO
Oil Resistant
Yes
UV Resistant
YES
Halogen Free
YES
Submersible
NO
Direct Burial
NO
Movement Type
Continuous Flex
Application
Control, Data
Gauge
22 AWG
Pair count
27
Number of conductors
54
Cable configuration
22 AWG (≈ 42/38)/27pr
Stranding type
bare copper, extra fine strands
Insulation type
SABIX
Shielded
Yes
Voltage
500
Approvals
CE, EAC, RoHS
RoHS
YES

Temperature range

-40°C to +90°C

Outside diameter (OD)

0.705 in

UOM

CSA Certification

UL Certification

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

67452734 Description

SAB 67452734 Halogen Free Cable is part of SABIX® SD 745 C FRNC C1 TP product family, and is designed for Control, Data applications. This cable is 22 AWG with 54 conductors, and shielded 22 AWG (≈ 42/38)/27pr cable configuration. Featuring Black color jacket, SABIX insulation, and bare copper, extra fine strands stranding. It has 0.705 in OD, constructed to support Continuous Flex movement type, and rated for 500 volts. This Control, Data cable can operate in -40°C to +90°C temperature range, it is oil resistant, UV resistand, Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.
