64450825 SAB Halogen Free Cables

SAB 64450825 SABIX BL 445 C FRNC TP - 24 AWG/8pr, shielded halogen-free flame retardant paired flexible data cable for shipboard, DNV-GL, CE, RoHS
SAB

Part#:64450825

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX BL 445 C FRNC TP - 24 AWG/8pr, shielded halogen-free flame retardant paired flexible data cable for shipboard, DNV-GL, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 64450825 SAB price in the box on the right side or send a quick quote.

Product Details

  • UV Resistant
    NO
  • Application
    Control, Data
  • Cable configuration
    24 AWG (≈ 14/34)/8pr
  • Approvals
    DNV, CE, EAC, RoHS
  • Oil Resistant
    No
  • Direct Burial
    NO
  • Stranding type
    tinned copper strands, class 5
  • RoHS
    YES
  • Outside diameter (OD)
    0.358 in
  • CE Certification
    YES
  • Weight
    36.74 g
  • Temperature range
    -40°C to +90°C
  • Chemical Resistant
    NO
  • Submersible
    NO
  • Pair count
    8
  • Shielded
    Yes
  • Gauge
    24 AWG
  • Insulation type
    SABIX
  • Voltage
    350
  • CSA Certification
    NO
  • UOM
    ft
  • UL Certification
    NO
  • Halogen Free
    YES
  • Number of conductors
    16
  • Movement Type
    Stationary/Flexible
  • Color
    Pigeon Blue

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

64450825 Description

SAB 64450825 Halogen Free Cable is part of SABIX® BL 445 C FRNC TP product family, and is designed for Control, Data applications. This cable is 24 AWG with 16 conductors, and shielded 24 AWG (≈ 14/34)/8pr cable configuration. Featuring Pigeon Blue color jacket, SABIX insulation, and tinned copper strands, class 5 stranding. It has 0.358 in OD, constructed to support Stationary/Flexible movement type, and rated for 350 volts. This Control, Data cable can operate in -40°C to +90°C temperature range, it is Halogen free, and has following approvals: DNV, CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.

Related documents 64450825 Specs

64450825 SABIX_BL_445_C_FRNC_TP.pdf
