64380710 SAB Halogen Free Cables
Part#:64380710
Manufacturer:SAB
Product Lifecycle:Active
Get a quick Quote!
SABIX BL 438 C FRNC - 18 AWG/7c, shielded halogen-free flame retardant flexible control cable for shipboard, DNV-GL, CE, RoHS
About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.
Check out the 64380710 SAB price in the box on the right side or send a quick quote.
Product Details
- Voltage 500
- Chemical Resistant NO
- Outside diameter (OD) 0.354 in
- CE Certification YES
- Submersible NO
- Application Control, Power
- Weight 44.00 g
- Insulation type SABIX
- Cable configuration 18 AWG (≈ 30/32)/7c
- Color Pigeon Blue
- Temperature range -40°C to +90°C
- Shielded Yes
- CSA Certification NO
- UV Resistant NO
- Direct Burial NO
- Movement Type Stationary/Flexible
- Approvals DNV, CE, EAC, RoHS
- UOM ft
- Oil Resistant No
- Gauge 18 AWG
- Number of conductors 7
- Stranding type tinned copper strands, class 5
- RoHS YES
- UL Certification NO
- Halogen Free YES
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
64380710 Description
SAB 64380710 Halogen Free Cable is part of SABIX® BL 438 C FRNC product family, and is designed for Control, Power applications. This cable is 18 AWG with 7 conductors, and shielded 18 AWG (≈ 30/32)/7c cable configuration. Featuring Pigeon Blue color jacket, SABIX insulation, and tinned copper strands, class 5 stranding. It has 0.354 in OD, constructed to support Stationary/Flexible movement type, and rated for 500 volts. This Control, Power cable can operate in -40°C to +90°C temperature range, it is Halogen free, and has following approvals: DNV, CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.
Related documents 64380710 Specs
