64150750 SAB Halogen Free Cables

SAB 64150750 SABIX BL 415 C FRNC - 20 AWG/7c, shielded halogen-free flame retardant data cable, DNV-GL, CE, RoHS
SAB

Part#:64150750

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX BL 415 C FRNC - 20 AWG/7c, shielded halogen-free flame retardant data cable, DNV-GL, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 64150750 SAB price in the box on the right side or send a quick quote.

Product Details

  • Color
    Pigeon Blue
  • Weight
    27.22 g
  • Chemical Resistant
    NO
  • Oil Resistant
    No
  • UV Resistant
    NO
  • Halogen Free
    YES
  • Submersible
    NO
  • Direct Burial
    NO
  • Movement Type
    Stationary/Flexible
  • Application
    Control, Data, Power
  • Gauge
    20 AWG
  • Number of conductors
    7
  • Cable configuration
    20 AWG (≈ 16/32)/7c
  • Stranding type
    tinned copper strands, class 5
  • Insulation type
    SABIX
  • Shielded
    Yes
  • Voltage
    350
  • Approvals
    DNV, CE, EAC, RoHS
  • RoHS
    YES
  • Temperature range
    -40°C to +90°C
  • Outside diameter (OD)
    0.283 in
  • UOM
    ft
  • CSA Certification
    NO
  • UL Certification
    NO
  • CE Certification
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

64150750 Description

SAB 64150750 Halogen Free Cable is part of SABIX® BL 415 C FRNC product family, and is designed for Control, Data, Power applications. This cable is 20 AWG with 7 conductors, and shielded 20 AWG (≈ 16/32)/7c cable configuration. Featuring Pigeon Blue color jacket, SABIX insulation, and tinned copper strands, class 5 stranding. It has 0.283 in OD, constructed to support Stationary/Flexible movement type, and rated for 350 volts. This Control, Data, Power cable can operate in -40°C to +90°C temperature range, it is Halogen free, and has following approvals: DNV, CE, EAC, RoHS. This cable is an excellent choice for Control, Data, Power applications.

Related documents 64150750 Specs

64150750 SABIX_BL_415_C_FRNC.pdf
