63052414 SAB Halogen Free Cables

Name: 63052414
Brand: SAB

Part#:63052414

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX D 305 FRNC - 26 AWG/24c, halogen-free flame retardant flexible SABIX data cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 63052414 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Grayish Tan
Weight
24.49 g
Chemical Resistant
NO
Oil Resistant
No
UV Resistant
NO
Halogen Free
YES
Submersible
NO
Direct Burial
NO
Movement Type
Stationary/Flexible
Application
Data
Gauge
26 AWG
Number of conductors
24
Cable configuration
26 AWG (≈ 18/38)/24c
Stranding type
bare copper, fine strands
Insulation type
SABIX
Shielded
No
Voltage
300
Approvals
CE, EAC, RoHS
RoHS
YES
Temperature range
-40°C to +85°C

Outside diameter (OD)

0.295 in

UOM

CSA Certification

UL Certification

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

63052414 Description

SAB 63052414 Halogen Free Cable is part of SABIX® D 305 FRNC product family, and is designed for Data applications. This cable is 26 AWG with 24 conductors, and 26 AWG (≈ 18/38)/24c cable configuration. Featuring Grayish Tan color jacket, SABIX insulation, and bare copper, fine strands stranding. It has 0.295 in OD, constructed to support Stationary/Flexible movement type, and rated for 300 volts. This Data cable can operate in -40°C to +85°C temperature range, it is Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Data applications.
