61570986 SAB Halogen Free Cables

SAB 61570986 SABIX A 157 FRNC - 12 AWG/1c, flame retardant halogen-free 1000V orange hook-up wire, UL, CE, RoHS
SAB

Part#:61570986

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX A 157 FRNC - 12 AWG/1c, flame retardant halogen-free 1000V orange hook-up wire, UL, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 61570986 SAB price in the box on the right side or send a quick quote.

Product Details

  • Color
    Orange
  • Weight
    14.06 g
  • Chemical Resistant
    NO
  • Oil Resistant
    No
  • UV Resistant
    YES
  • Halogen Free
    YES
  • Submersible
    NO
  • Direct Burial
    NO
  • Movement Type
    Stationary/Flexible
  • Application
    Control, Power
  • Gauge
    12 AWG
  • Number of conductors
    1
  • Cable configuration
    12 AWG/1c
  • Stranding type
    bare copper strands, class 5
  • Shielded
    No
  • Voltage
    1000
  • Approvals
    UR AWM, CE, EAC, RoHS
  • RoHS
    YES
  • Temperature range
    -40°C to +90°C
  • Outside diameter (OD)
    0.169 in
  • UOM
    ft
  • CSA Certification
    NO
  • UL Certification
    YES
  • CE Certification
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

61570986 Description

SAB 61570986 Halogen Free Cable is part of SABIX® A 157 FRNC product family, and is designed for Control, Power applications. This cable is 12 AWG with 1 conductors, and 12 AWG/1c cable configuration. Featuring Orange color jacket, and bare copper strands, class 5 stranding. It has 0.169 in OD, constructed to support Stationary/Flexible movement type, and rated for 1000 volts. This Control, Power cable can operate in -40°C to +90°C temperature range, it is UV resistand, Halogen free, and has following approvals: UR AWM, CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.

Related documents 61570986 Specs

61570986 SABIX_A_147_FRNC-SABIX_A_157_FRNC.pdf
