31800725 SAB High Temperature Cables
Part#:31800725
Manufacturer:SAB
Product Lifecycle:Active
Get a quick Quote!
S 180 HT - 14 AWG/7c, high temperature continuous flex silicone cable, CE, RoHS
About the manufacturer: SAB is one of the manufacturers that offers High Temperature Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.
Check out the 31800725 SAB price in the box on the right side or send a quick quote.
Product Details
- CSA Certification NO
- UL Certification NO
- Chemical Resistant NO
- UV Resistant NO
- Direct Burial NO
- Weight 97.52 g
- Oil Resistant No
- Application Control, Power
- Gauge 14 AWG
- Cable configuration 14 AWG (≈ 140/34)/7c
- Stranding type tinned copper strands, class 6
- Shielded No
- CE Certification YES
- Halogen Free NO
- Submersible NO
- Movement Type Continuous Flex
- Number of conductors 7
- Insulation type FEP
- Color Gray
- Voltage 1000
- Approvals CE, EAC, RoHS
- RoHS YES
- Temperature range -25°C to +180°C; +200°C (short-term use)
- Outside diameter (OD) 0.531 in
- UOM ft
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
31800725 Description
SAB 31800725 High Temperature Cable is part of S 180 HT product family, and is designed for Control, Power applications. This cable is 14 AWG with 7 conductors, and 14 AWG (≈ 140/34)/7c cable configuration. Featuring Gray color jacket, FEP insulation, and tinned copper strands, class 6 stranding. It has 0.531 in OD, constructed to support Continuous Flex movement type, and rated for 1000 volts. This Control, Power cable can operate in -25°C to +180°C; +200°C (short-term use) temperature range, it is and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.
Related documents 31800725 Specs
