31470880 SAB Hook-Up Wire

Name: 31470880
Brand: SAB

SAB 31470880 MEGA 147/H05V2-K/H05V-K (HAR/UL/CSA/CE) - 18 AWG hook-up wire, White

Part#:31470880

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

MEGA 147/H05V2-K/H05V-K (HAR/UL/CSA/CE) - 18 AWG hook-up wire, White

About the manufacturer: SAB is one of the manufacturers that offers Hook-Up Wire that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 31470880 SAB price in the box on the right side or send a quick quote.

Product Details

Color
White
Weight
4.99 g
Chemical Resistant
NO
Oil Resistant
No
UV Resistant
NO
Halogen Free
NO
Submersible
NO
Direct Burial
NO
Movement Type
Stationary/Flexible
Application
Control, Power
Gauge
18 AWG
Number of conductors
1
Cable configuration
18 AWG/1c
Stranding type
tinned copper strands, class 5
Shielded
No
Voltage
600
Approvals
UR AWM, VDE, , CE, EAC, RoHS
RoHS
YES
Temperature range
-40°C to +105°C
Outside diameter (OD)
0.110 in

UOM

CSA Certification

UL Certification

YES

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

31470880 Description

SAB 31470880 European Standardized Cable is part of MEGA 147/H05V2-K/H05V-K product family, and is designed for Control, Power applications. This cable is 18 AWG with 1 conductors, and 18 AWG/1c cable configuration. Featuring White color jacket, and tinned copper strands, class 5 stranding. It has 0.11 in OD, constructed to support Stationary/Flexible movement type, and rated for 600 volts. This Control, Power cable can operate in -40°C to +105°C temperature range, it is and has following approvals: UR AWM, VDE, <HAR>, CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.
