15672625 SAB Ethernet Cables

SAB 15672625 CATLine CAT5e R - 26 AWG/2pr, shielded halogen-free CAT 5e ethernet cable for Rail applications, CE, RoHS
SAB

Part#:15672625

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

CATLine CAT5e R - 26 AWG/2pr, shielded halogen-free CAT 5e ethernet cable for Rail applications, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Ethernet Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 15672625 SAB price in the box on the right side or send a quick quote.

Product Details

  • Oil Resistant
    No
  • CE Certification
    YES
  • Submersible
    NO
  • Insulation type
    PE
  • Chemical Resistant
    NO
  • Halogen Free
    YES
  • Gauge
    24 AWG
  • Outside diameter (OD)
    0.157 in
  • Shielded
    Yes
  • Direct Burial
    NO
  • Number of conductors
    4
  • Color
    Green
  • CSA Certification
    NO
  • Movement Type
    Torsional
  • Cable configuration
    26 AWG (≈ 18/38)/2pr
  • Voltage
    90
  • Temperature range
    -40°C to +70°C
  • UL Certification
    NO
  • Application
    Data
  • Pair count
    2
  • Weight
    7.71 g
  • UV Resistant
    NO
  • UOM
    ft
  • Approvals
    CE, EAC, RoHS
  • Stranding type
    bare copper, fine strands
  • RoHS
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

15672625 Description

SAB 15672625 Ethernet Cable is part of CATLine CAT 5e R product family, and is designed for Data applications. This cable is 24 AWG with 4 conductors, and shielded 26 AWG (≈ 18/38)/2pr cable configuration. Featuring Green color jacket, PE insulation, and bare copper, fine strands stranding. It has 0.157 in OD, constructed to support Torsional movement type, and rated for 90 volts. This Data cable can operate in -40°C to +70°C temperature range, it is Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Data applications.

Related documents 15672625 Specs

15672625 CATLine_CAT_5e_6A_7A_R.pdf
