PILZ-774321 Pilz Electrical Safety Devices

Pilz PILZ-774321 is a safety relay designed for single or dual-channel operation with capabilities for safety gate monitoring, instantaneous E-STOP monitoring, and limit switch monitoring. It features DIN rail mounting and operates within an ambient air temperature range of -10 to +55°C. The device has a net height of 87 mm and supports both automatic and manual start modes. It offers rated current safety output contacts ratings of 4A at 24Vdc (DC-1), 6A at 240Vac (AC-1), 4A at 24Vdc (DC-13), and 5A at 230Vac (AC-15). Connection is facilitated through fixed screw terminal connections, and it operates on a supply voltage of 20.4-26.4Vac (24Vac nominal) or 20.4-26.4Vdc (24Vdc nominal), belonging to the PNOZ X5J sub-range. The dimensions include a width of 22.5mm and a degree of protection rated at IP40. The housing is made of PPO with an ABS front, and the net width is 22.5 mm. Power consumption is rated at 2 W, with a net depth of 121 mm. Its operating modes include detection of earth faults in the start and input circuit for single-channel operation and additional detection of short circuits in the input circuit for dual-channel operation. It features 2 x instantaneous safety outputs and 2 x digital inputs plus 1 x start input, allowing for the connection of contact expansion modules or external contactors/relays to increase the number of available contacts.

About the manufacturer: Pilz is one of the manufacturers that offers Electrical Safety Devices that you can order at Advantage Electric Supply site. We are at the forefront of driving the evolution of industrial automation. Our company ethos is built on dedication and principles, placing a high priority on safety. Over the years, we have been devoted to creating cutting-edge products and solutions tailored to our customers' requirements.

Check out the PILZ-774321 Pilz price in the box on the right side or send a quick quote.
