STZ240D45B1 Mersen Electronic Components
Part#:STZ240D45B1
Alt. Part#:0782001478766
Manufacturer:Mersen
Category:Electronic Components
Product Lifecycle:Active
Product description
SPD - Type 1 STZ 240V D 450kA B1
Product Details
- Sell Pack Height 11.25 in
- Sell Pack Length 21.88 in
- Product Width 12.98 in
- Sell Pack Width 16.63 in
- Product Length 13.52 in
- Product Weight 30.45 lb
- Sell Pack Weight 30.45 lb
- Sell Pack Quantity 1 Each
- VPR L-L 2500 V
- Product Height 6.29 in
- VPR L-G 1200 V
- Installation Mounting Panel or Wall Mount
- Housing Material Steel
- MCOV L-G 320 V
- Enclosure NEMA Type 4
- MCOV L-L 640 V
- Connection/Terminal Type Box
- Indication System Type LED and Remote Audible Alarm
- Indication System Yes
- Nominal Discharge Current (In) (8/20) 20kA
- Short Circuit Current Rating (SCCR) 200 kA
- Frequency 50/60 Hz
- Protection Modes L-G, L-L, L-N, N-G
- AC or DC AC
- Nominal Operating Volt Rating (Un) 240 V
- System Configuration 3-Phase Delta
- UL SPD Type Type 1
- Max Discharge Current : Imax (8/20) 450 kA per phase
- ROHS Compliant Yes
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of STZ240D45B1 on Advantage Electric Supply is $28,396.17. Order now.
