ST2771PG Mersen Electronic Components
Part#:ST2771PG
Alt. Part#:782001361419
Manufacturer:Mersen
Category:Electronic Components
Product Lifecycle:Active
Product description
SPD - Modular ST Series 270V 50 kA 1-pole Visual Ind
Product Details
- UL SPD Type Type 1 Component Assembly
- Short Circuit Current Rating (SCCR) 200 (most models) kA
- MCOV L-G 320 V
- Product Height 2.7 in
- Sell Pack Quantity 3 Each
- ROHS Compliant Yes
- Connection/Terminal Type Box
- VPR L-G 900 V
- Nominal Discharge Current (In) (8/20) 20 kA
- Nominal Operating Volt Rating (Un) 270 V
- Number of Poles 1-pole
- Installation Mounting DIN Rail
- Sell Pack Width 2.88 in
- Sell Pack Height 2.75 in
- Max Discharge Current : Imax (8/20) 50 kA per phase
- Wiring range #6 to #14 AWG
- Number of Wires 2 Wire
- MOV Response Time <25 ns
- Sell Pack Length 4.88 in
- AC or DC AC
- Indication System Yes
- System Configuration Single Phase
- Product Weight 0.25 lb
- Product Width 0.7 in
- Protection Modes L-G, L-N
- Connection/Terminal Material Zinc-Plated Steel
- MCOV L-N 320 V
- Product Length 3.58 in
- Indication System Type Visual Indicator
- Housing Material PET (Polyethelene Terphthalate)
- VPR L-N 900 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
