Q1000077 Mersen Electronic Components
Part#:Q1000077
Alt. Part#:3605340452228
Manufacturer:Mersen
Category:Electronic Components
Product Lifecycle:Active
Product description
NH fuse-link aM, 690VAC, size 4, 630A with striker
Product Details
- Ampere Rating 630 A
- Catalogue No. NH4AM69V630P-2
- Sell Pack Weight 4.85 lb
- Speed/Characteristic aM
- Sell Pack Quantity 1 EACH
- AC Max I.R./Breaking Capacity: I1 120 kA
- Product Length 7.85 in
- Rated voltage AC IEC 690 V
- Product Width 3.94 in
- Sell Pack Length 8.86 in
- Indication System Yes
- Product Height 4.61 in
- Power Dissipation at Rated Current Value 50 W
- Connection/Terminal Material Silver-Plated Copper
- Sell Pack Height 5.91 in
- Fuse Size NH4
- Indication System Type Striker
- ROHS Compliant Yes
- Product Weight 4.85 lb
- Sell Pack Width 4.13 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
