OTM8 Mersen Fuses
Part#:OTM8
Manufacturer:Mersen
Alt. Part#:782001705084
Product Lifecycle:Active
Get a quick Quote!
OTM8 Mersen - Fuse OTM - Midget - Fast-Acting 250VAC 8A Ferrule Amp-Trap®
About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the OTM8 Mersen price in the box on the right side or send a quick quote.
Product Details
- Current Rating 8 A
- Terminal Type Ferrule
- Material Paper
- Type Low Voltage UL/CSA Fuses
- Weight 5.442 g
- Voltage 250 VAC
- Approvals *UL Listed to standard 248-14, File E33925 *CSA Certified to Standard C22.2 No. 248.14
- UL Certification YES
- Trip Class Fast-Acting
- Fuse Class Midget
- Sell Pack Height 2.12 in
- Sell Pack Length 1.62 in
- Product Diameter 0.41 in
- Product Length 1.5 in
- Sell Pack Weight 0.13 lb
- Connection/Terminal Type Ferrule
- Sell Pack Width 0.88 in
- Product Weight 0.012 lb
- Body/Insulating Material Paper
- Sell Pack Quantity 10 Each
- Mounting Clip
- Connection/Terminal Material Tin-Plated Copper
- Speed/Characteristic Fast-Acting
- ROHS Compliant Yes
- Ampere Rating 8 A
- Fuse Class Midget
- AC Max I.R./Breaking Capacity: I1 10 kA
- Rated voltage AC UL 250 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
OTM8 Description
OTM8 Mersen - Fuse OTM - Midget - Fast-Acting 250VAC 8A Ferrule Amp-Trap®
Related documents OTM8 Specs
Manufacturer warranty
