F331021 Mersen Fuse Holders
Part#:F331021
Manufacturer:Mersen
Alt. Part#:8430399014470
Product Lifecycle:Active
Get a quick Quote!
F331021 Mersen - Fuse Holder Modulostar® Size 14x51 IEC 690VAC 690VDC 4-Pole IP20
About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the F331021 Mersen price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 4 Pole
- Current Rating 50 A
- Weight 570.678 g
- Sell Pack Length 6.46 in
- Sell Pack Width 4.45 in
- Product Height 4.36 in
- Sell Pack Quantity 1 EACH
- Sell Pack Weight 1.257 lb
- Product Length 3.01 in
- Sell Pack Height 3.11 in
- Product Weight 1.257 lb
- Rated Insulation Voltage 690 V
- Rated Impulse Withstand Voltage 8
- Product Width 4.17 in
- Installation Mounting DIN rail acc. EN 60715
- Torque Rating 30.98 lb-in
- Conventional Free Air thermal Current With Fuse-Links Ith 50 A
- Comments Wiring tool : PZ2 or flat 5.5x1mm screw drivers recommended (max. diameter 6mm)
- Ampere Rating 50 A
- Rated voltage AC IEC 690 V
- Catalogue No. CMS144
- Rated voltage DC IEC 690 V
- ROHS Compliant Yes
- Fuse Size 14x51
- Short Circuit Current Rating (SCCR) 100 kA
- Number of Poles 4-Pole
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
F331021 Description
F331021 Mersen - Fuse Holder Modulostar® Size 14x51 IEC 690VAC 690VDC 4-Pole IP20 | The innovative and comprehensive Modulostar® range of Mersen fuse-holders. Modular fuse-holders are finger-safe under IEC standards to an IP20 grade of protection, including fuse changing (with the flick of a finger). Modular fuse-holders are available in 1, 2, 3 or 4 poles, with or without visual blown fuse indicator, in IEC version or IEC + UL version. Multi-pole units can also be field assembled by ordering pin-ties assembly kit. In size 14 or 22, the range also offers the possibility to use microswitches (supplied with the holders or ordered separately) to allow remote indication. Modulostar® range is made of tough and durable thermoplastic or thermoset material. | Features: *Finger safe
*Degree of protection: IP20
*Optional visual blown fuse indicator
*DIN rail mounting
*Modular design
*Lockable
*Multi-pole assembly kit available
*Sealable in closed and open position
*Plastic material UL94V2 mini
*Flame retardant materials with glow wire flammability index to 960°C
*Shock and vibration tested for marine and railway applications | Application: *All circuits up to 690V for protection of motors, transformers,
*low voltage distribution, control circuits, drive protection
*Non-load operation
Related documents F331021 Specs
