A6D2-8/10R Mersen Fuses

Mersen A6D2-8/10R A6D2-8/10R Mersen - Fuse A6D-R - Class RK1 - Time-Delay 600VAC 600VDC 2.8A Ferrule Amp-Trap 2000®
Mersen

Part#:A6D2-8/10R

Manufacturer:Mersen

Alt. Part#:782001307875

Product Lifecycle:Active

Get a quick Quote!

A6D2-8/10R Mersen - Fuse A6D-R - Class RK1 - Time-Delay 600VAC 600VDC 2.8A Ferrule Amp-Trap 2000®

About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the A6D2-8/10R Mersen price in the box on the right side or send a quick quote.

Product Details

  • Current Rating
    2.8 A
  • Terminal Type
    Ferrule
  • Material
    PolyTube
  • Type
    Low Voltage UL/CSA Fuses
  • Weight
    66.211 g
  • Voltage
    600 VAC / 600 VDC
  • Approvals
    *UL listed to standard 248-12 File E2137 *DC listed to UL standard 248 *CSA certified to standard C22.2 No. 248.12
  • UL Certification
    YES
  • Trip Class
    Time Delay
  • Fuse Class
    Class RK1
  • Sell Pack Height
    1.75 in
  • Sell Pack Length
    5.12 in
  • Sell Pack Width
    4.12 in
  • Sell Pack Quantity
    10 Each
  • Sell Pack Weight
    1.47 lb
  • Product Diameter
    0.81 in
  • Product Weight
    0.14 lb
  • Product Length
    5 in
  • Speed/Characteristic
    Time Delay
  • Body/Insulating Material
    PolyTube
  • AC Max I.R./Breaking Capacity: I1
    200 kA
  • Mounting
    Clip
  • Rated voltage AC UL
    600 V
  • Fuse Class
    Class RK1
  • Rated voltage DC UL
    600 V
  • Ampere Rating
    2.8 A
  • Connection/Terminal Type
    Ferrule
  • Connection/Terminal Material
    Tin-Plated Copper

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

A6D2-8/10R Description

A6D2-8/10R Mersen - Fuse A6D-R - Class RK1 - Time-Delay 600VAC 600VDC 2.8A Ferrule Amp-Trap 2000®

Related documents A6D2-8/10R Specs

A6D2-8/10R 2313D8AD414A4F918E802FDAC22120D7-1en.pdf
